Icom IC-FR6000 Service Manual Addendum page 38

July 2016
[MAIN-E UNIT]
REF PART
DESCRIPTION
NO. NO.
R328 7030000260 S.RES MCR10EZHJ 100 (101)
R331 7030004980 S.RES ERJ2GEJ 101 X (100)
R332 7030003320 S.RES ERJ3GEYJ 101 V (100)
R333 7030007350 S.RES ERJ2GEJ 393 X (39K)
R334 7030005651 S.RES ERA3YKD 304V (300K)
R335 7030005871 S.RES ERA3YKD 104V (100K)
R336 7030005110 S.RES ERJ2GEJ 224 X (220K)
R337 7030005110 S.RES ERJ2GEJ 224 X (220K)
R339 7030005090 S.RES ERJ2GEJ 104 X (100K)
R341 7030005050 S.RES ERJ2GEJ 103 X (10K)
R342 7030005090 S.RES ERJ2GEJ 104 X (100K)
R346 7410001150 S.ARR EXB28V471JX
R347 7030005040 S.RES ERJ2GEJ 472 X (4.7K)
R348 7030000620 S.RES MCR10EZHJ 100 K (104)
R349 7030000620 S.RES MCR10EZHJ 100 K (104)
R350 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R352 7030005040 S.RES ERJ2GEJ 472 X (4.7K)
R353 7030005240 S.RES ERJ2GEJ 473 X (47K)
R354 7030005700 S.RES ERJ2GEJ 274 X (270K)
R355 7030005090 S.RES ERJ2GEJ 104 X (100K)
R356 7030005090 S.RES ERJ2GEJ 104 X (100K)
R357 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R362 7540000290 ABS ERZV10D220
R364 7030005110 S.RES ERJ2GEJ 224 X (220K)
R365 7030005050 S.RES ERJ2GEJ 103 X (10K)
R366 7030007290 S.RES ERJ2GEJ 222 X (2.2K)
R367 7030004980 S.RES ERJ2GEJ 101 X (100)
R368 7030008300 S.RES ERJ2GEJ 184 X (180K)
R369 7030005230 S.RES ERJ2GEJ 334 X (330K)
R370 7030008280 S.RES ERJ2GEJ 271 X (270)
R371 7030010040 S.RES ERJ2GEJ-JPW
R372 7030005000 S.RES ERJ2GEJ 471 X (470)
R373 7030005050 S.RES ERJ2GEJ 103 X (10K)
R374 7030000140 S.RES MCR10EZHJ 10 (100)
R375 7030010040 S.RES ERJ2GEJ-JPW
R376 7030004980 S.RES ERJ2GEJ 101 X (100)
R377 7030007280 S.RES ERJ2GEJ 331 X (330)
R378 7030005210 S.RES ERJ2GEJ 822 X (8.2K)
R379 7030005210 S.RES ERJ2GEJ 822 X (8.2K)
R380 7030007260 S.RES ERJ2GEJ 330 X (33)
R381 7030007270 S.RES ERJ2GEJ 151 X (150)
R424 7410001150 S.ARR EXB28V471JX
R425 7410001150 S.ARR EXB28V471JX
R426 7410001150 S.ARR EXB28V471JX
R427 7030005000 S.RES ERJ2GEJ 471 X (470)
R428 7410001140 S.ARR EXB28V104JX
R429 7410001140 S.ARR EXB28V104JX
R430 7410001140 S.ARR EXB28V104JX
R431 7410001150 S.ARR EXB28V471JX
R432 7410001140 S.ARR EXB28V104JX
R433 7410001150 S.ARR EXB28V471JX
R434 7410000750 S.ARR EXB-V4V 104JV (100K)
R435 7410001140 S.ARR EXB28V104JX
R436 7410001140 S.ARR EXB28V104JX
R438 7410001140 S.ARR EXB28V104JX
R443 7030005000 S.RES ERJ2GEJ 471 X (470)
R444 7030005240 S.RES ERJ2GEJ 473 X (47K)
R445 7030005240 S.RES ERJ2GEJ 473 X (47K)
R446 7030005240 S.RES ERJ2GEJ 473 X (47K)
R448 7030005090 S.RES ERJ2GEJ 104 X (100K)
R449 7030005170 S.RES ERJ2GEJ 474 X (470K)
R450 7030005050 S.RES ERJ2GEJ 103 X (10K)
R452 7030005090 S.RES ERJ2GEJ 104 X (100K)
R454 7030005120 S.RES ERJ2GEJ 102 X (1K)
R455 7030005010 S.RES ERJ2GEJ 681 X (680)
R456 7030005120 S.RES ERJ2GEJ 102 X (1K)
R467 7030005240 S.RES ERJ2GEJ 473 X (47K)
R468 7030005090 S.RES ERJ2GEJ 104 X (100K)
R469 7030005090 S.RES ERJ2GEJ 104 X (100K)
R470 7030005090 S.RES ERJ2GEJ 104 X (100K)
R471 7030005090 S.RES ERJ2GEJ 104 X (100K)
R472 7030005240 S.RES ERJ2GEJ 473 X (47K)
R473 7030005090 S.RES ERJ2GEJ 104 X (100K)
R474 7030005530 S.RES ERJ2GEJ 100 X (10)
R475 7030005240 S.RES ERJ2GEJ 473 X (47K)
R476 7030008270 S.RES RR0510P-104-D (100K)
R477 7030005860 S.RES RR0510P-823-D (82K)
R478 7030005050 S.RES ERJ2GEJ 103 X (10K)
R479 7030005110 S.RES ERJ2GEJ 224 X (220K)
R480 7030005050 S.RES ERJ2GEJ 103 X (10K)
R481 7030005050 S.RES ERJ2GEJ 103 X (10K)
R482 7410001150 S.ARR EXB28V471JX
R483 7030005090 S.RES ERJ2GEJ 104 X (100K)
R484 7030005090 S.RES ERJ2GEJ 104 X (100K)
R485 7410001150 S.ARR EXB28V471JX
R486 7410001150 S.ARR EXB28V471JX
R487 7410001150 S.ARR EXB28V471JX
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
(Amended page)
[MAIN-E UNIT]
H/V REF PART
M.
LOCATION NO. NO.
B 139.3/144.4 R488 7030008400 S.RES ERJ2GEJ 182 X (1.8K)
T 12.0/120.0 R489 7030004980 S.RES ERJ2GEJ 101 X (100)
B 139.5/135.1 R490 7030008290 S.RES ERJ2GEJ 183 X (18K)
B 139.4/131.4 R491 7030004980 S.RES ERJ2GEJ 101 X (100)
T 57.8/30.5 R492 7030005060 S.RES ERJ2GEJ 333 X (33K)
T 55.9/29.8 R493 7030010040 S.RES ERJ2GEJ-JPW
T 12.0/120.9 R494 7030005000 S.RES ERJ2GEJ 471 X (470)
T 13.2/120.6 R495 7030007060 S.RES ERJ2GEJ 684X (680K)
T 12.0/125.3 R496 7030010030 S.RES ERJ2RHD 9102X (91.0K)
B 33.3/12.0 R497 7030005700 S.RES ERJ2GEJ 274 X (270K)
B 45.3/56.9 R498 7030005600 S.RES ERJ2GEJ 273 X (27K)
T 43.6/73.8 R499 7030004980 S.RES ERJ2GEJ 101 X (100)
T 9.9/132.9 R500 7030005600 S.RES ERJ2GEJ 273 X (27K)
B 147.3/150.9 R501 7030005220 S.RES ERJ2GEJ 223 X (22K)
B 26.0/149.7 R502 7030005090 S.RES ERJ2GEJ 104 X (100K)
B 6.4/131.1 R503 7030007350 S.RES ERJ2GEJ 393 X (39K)
T 10.8/125.6 R505 7030010040 S.RES ERJ2GEJ-JPW
B 55.8/56.9 R506 7030005110 S.RES ERJ2GEJ 224 X (220K)
T 125.2/103.7 R507 7030005090 S.RES ERJ2GEJ 104 X (100K)
T 129.2/103.7 R508 7030010040 S.RES ERJ2GEJ-JPW
T 10.8/133.9 R509 7030005050 S.RES ERJ2GEJ 103 X (10K)
B 10.2/150.2 R510 7030007350 S.RES ERJ2GEJ 393 X (39K)
R511 7030005050 S.RES ERJ2GEJ 103 X (10K)
T 65.1/71.2 R512 7030005050 S.RES ERJ2GEJ 103 X (10K)
T 7.5/120.7 R513 7030007280 S.RES ERJ2GEJ 331 X (330)
T 6.3/122.7 R530 7030005600 S.RES ERJ2GEJ 273 X (27K)
T 9.8/117.3 R532 7030005000 S.RES ERJ2GEJ 471 X (470)
T 8.6/117.8 R533 7030005090 S.RES ERJ2GEJ 104 X (100K)
T 9.8/118.2 R534 7030005600 S.RES ERJ2GEJ 273 X (27K)
T 6.2/120.7 R535 7030004980 S.RES ERJ2GEJ 101 X (100)
T 5.1/117.3 R536 7030005600 S.RES ERJ2GEJ 273 X (27K)
T 115.3/15.8 R537 7030010040 S.RES ERJ2GEJ-JPW
T 115.3/14.0 R539 7030005100 S.RES ERJ2GEJ 154 X (150K)
T 111.2/12.3 R540 7030005090 S.RES ERJ2GEJ 104 X (100K)
T 100.1/16.3 R541 7030005220 S.RES ERJ2GEJ 223 X (22K)
B 62.3/122.2 R542 7030005110 S.RES ERJ2GEJ 224 X (220K)
B 62.3/124.7 R543 7030005080 S.RES ERJ2GEJ 823 X (82K)
B 63.2/126.1 R546 7030010040 S.RES ERJ2GEJ-JPW
B 59.6/126.1 R548 7030001070 S.RES MCR50JZHJ 33 (330)
B 57.8/123.7 R549 7030001070 S.RES MCR50JZHJ 33 (330)
B 61.4/126.1 R551 7030010040 S.RES ERJ2GEJ-JPW
T 46.3/42.9 R553 7030010040 S.RES ERJ2GEJ-JPW
T 36.9/23.0 R557 7030010040 S.RES ERJ2GEJ-JPW
T 47.9/33.9 R560 7030006610 S.RES ERJ2GEJ 394 X (390K)
T 25.5/26.7 R561 7030005160 S.RES ERJ2GEJ 105 X (1M)
T 47.9/22.4 R562 7410001170 S.ARR EXB28V470JX
T 49.8/30.2 R563 7030005090 S.RES ERJ2GEJ 104 X (100K)
T 52.4/43.7 R565 7030010040 S.RES ERJ2GEJ-JPW
T 17.9/40.3 R566 7030004990 S.RES ERJ2GEJ 221 X (220)
T 15.2/48.2 R600 7030010040 S.RES ERJ2GEJ-JPW
T 40.0/22.7 R601 7030005120 S.RES ERJ2GEJ 102 X (1K)
B 36.8/48.3 R602 7030005120 S.RES ERJ2GEJ 102 X (1K)
B 39.2/47.6 R603 7030010040 S.RES ERJ2GEJ-JPW
B 44.4/41.2 R604 7030010040 S.RES ERJ2GEJ-JPW
B 34.5/47.8 R605 7030010040 S.RES ERJ2GEJ-JPW
T 60.4/59.2 R606 7030007570 S.RES ERJ2GEJ 122 X (1.2K)
B 13.5/33.6 R607 7030007570 S.RES ERJ2GEJ 122 X (1.2K)
B 13.5/36.1 R609 7030005120 S.RES ERJ2GEJ 102 X (1K)
B 13.5/37.4 R610 7030005050 S.RES ERJ2GEJ 103 X (10K)
T 49.8/19.2 R611 7030010040 S.RES ERJ2GEJ-JPW
T 39.5/19.3 R612 7030005120 S.RES ERJ2GEJ 102 X (1K)
T 50.2/17.1 R613 7030005120 S.RES ERJ2GEJ 102 X (1K)
T 51.0/19.0 R614 7030010040 S.RES ERJ2GEJ-JPW
B 95.0/2.8 R615 7030010040 S.RES ERJ2GEJ-JPW
B 125.0/2.8 R616 7030010040 S.RES ERJ2GEJ-JPW
B 110.0/2.8 R617 7030010040 S.RES ERJ2GEJ-JPW
B 37.7/44.6 R618 7030007570 S.RES ERJ2GEJ 122 X (1.2K)
B 26.3/44.6 R619 7030007570 S.RES ERJ2GEJ 122 X (1.2K)
B 32.6/44.6 R621 7030005120 S.RES ERJ2GEJ 102 X (1K)
T 10.9/20.2 R622 7030005050 S.RES ERJ2GEJ 103 X (10K)
B 47.7/44.2 R623 7030004970 S.RES ERJ2GEJ 470 X (47)
B 4.8/36.1 R624 7030004970 S.RES ERJ2GEJ 470 X (47)
B 46.2/44.6 R629 7030004970 S.RES ERJ2GEJ 470 X (47)
B 15.6/55.4 R632 7030004970 S.RES ERJ2GEJ 470 X (47)
B 9.6/53.2 R633 7030005050 S.RES ERJ2GEJ 103 X (10K)
B 15.0/53.5 R634 7030005050 S.RES ERJ2GEJ 103 X (10K)
B 15.0/52.6 R635 7030005050 S.RES ERJ2GEJ 103 X (10K)
B 9.2/54.8 R636 7030005050 S.RES ERJ2GEJ 103 X (10K)
T 64.2/69.6 R637 7030008370 S.RES ERJ2GEJ 561 X (560)
B 15.3/63.9 R638 7030005710 S.RES ERJ2GEJ 121 X (120)
B 14.0/63.5
T 19.6/45.2
T 31.3/56.5 C1 4030017420 S.CER C1005 CH 1H 470J-T
B 28.8/50.9 C2 4030017420 S.CER C1005 CH 1H 470J-T
T 67.3/97.1 C3 4030016930 S.CER C1005 JB 1A 104K-T
T 63.9/107.0 C4 4030017420 S.CER C1005 CH 1H 470J-T
T 74.0/107.3 C5 4030017420 S.CER C1005 CH 1H 470J-T
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
23
DESCRIPTION M.
LOCATION
T 9.5/54.9
B 24.1/58.7
B 28.3/58.4
B 26.1/51.2
B 29.9/58.9
T 11.3/19.0
T 73.8/99.0
T 55.2/55.3
T 52.7/56.2
T 52.7/55.3
B 61.4/103.1
T 24.4/57.0
T 21.2/57.5
T 22.8/53.8
T 28.0/55.0
T 55.5/58.4
T 113.4/18.3
T 113.4/19.3
T 115.0/19.3
T 144.6/119.6
B 33.3/15.2
B 29.0/14.1
B 29.1/18.5
B 30.8/18.5
B 72.3/90.4
T 62.5/66.3
B 44.6/37.0
T 57.2/18.4
B 45.3/58.6
B 55.8/55.3
B 55.8/58.6
B 41.8/41.1
T 64.2/71.2
T 90.6/17.9
T 28.9/55.0
B 43.7/72.9
B 46.0/70.8
B 141.9/91.0
T 87.0/33.3
T 87.0/30.2
B 15.5/60.5
B 15.9/59.3
B 10.3/62.6
T 140.8/130.2
T 140.8/131.1
B 32.3/49.8
T 42.1/62.4
B 15.3/62.2
T 141.4/121.5
B 124.6/41.5
B 124.6/42.4
B 124.6/43.3
B 118.3/48.0
T 119.2/41.5
B 121.1/49.7
B 90.2/40.7
B 92.3/41.2
B 120.9/38.5
B 126.0/45.6
B 31.0/78.3
B 31.9/78.3
B 32.8/78.3
B 37.5/84.2
T 32.4/81.0
B 39.3/81.5
T 33.3/84.5
B 33.8/99.2
B 35.4/99.2
B 28.5/80.9
B 35.3/72.0
T 30.3/22.3
T 30.3/23.2
T 45.1/23.6
T 44.1/22.7
B 118.1/61.6
B 117.2/61.6
T 36.3/74.8
T 33.5/75.1
B 49.8/78.0
B 18.8/37.5
B 122.3/37.0
B 25.8/79.3
B 130.8/48.3
B 126.9/37.1
B 21.0/78.3
H/V
