[MAIN UNIT]
REF ORDER
NO. NO.
W2 7120000470 JUM ERDS2T0
W4 8900017520 CAB OPC-1783
EP1 6910015370 S.BEA ACZ1005Y-102-T
EP2 6910015370 S.BEA ACZ1005Y-102-T
EP3 6910015370 S.BEA ACZ1005Y-102-T
EP4 6910016330 S.BEA MMZ1005S 601CT-S
EP5 6910015370 S.BEA ACZ1005Y-102-T
EP6 6910015370 S.BEA ACZ1005Y-102-T
EP7 6910016330 S.BEA MMZ1005S 601CT-S
EP8 6910015370 S.BEA ACZ1005Y-102-T
EP9 6910016330 S.BEA MMZ1005S 601CT-S
EP10 6910011560 BEA HF70BB4.5X5X1.6
EP13 6910011330 TER OT-009 M3
EP14 6910011330 TER OT-009 M3
DESCRIPTION M.
LOCATION
B 129.1/48.4
B 117.2/48.4
B 32.4/81.6
B 30.4/60.5
B
B
B 40.7/36.7
B 94.5/48.8
T 48.8/39.3
[FRONT UNIT]
H/V REF ORDER
NO. NO.
IC500 1130009121 S.IC
IC501 1110005771 S.IC
IC502 1140014580 S.IC
IC503 1110005350 S.IC
IC506 1140013200 S.IC
IC508 1110002751 S.IC
IC509 1110006770 S.IC
39/74.5
37.8/109
Q500 1590001050 S.TRA
Q501 1590001050 S.TRA
Q502 1590001050 S.TRA
Q503 1590001050 S.TRA
Q504 1590001050 S.TRA
Q506 1590001190 S.TRA
Q508 1520000460 S.TRA
Q510 1590001050 S.TRA
Q511 1590001050 S.TRA
Q513 1590001060 S.TRA
Q514 1590001060 S.TRA
Q515 1590001060 S.TRA
Q516 1590001060 S.TRA
Q517 1590001050 S.TRA
Q518 1590001050 S.TRA
D503 1790001260 S.DIO
1790001260 S.DIO
1790001261 S.DIO
1790001260 S.DIO
1790001260 S.DIO
1790001260 S.DIO
D504 1790001250 S.DIO
1790001250 S.DIO
1790001251 S.DIO
1790001250 S.DIO
1790001250 S.DIO
1790001250 S.DIO
D505 1790001450 S.DIO
D506 1790001450 S.DIO
D507 1790000950 S.ZEN
1790000950 S.ZEN
1790000951 S.ZEN
1790000950 S.ZEN
1790000950 S.ZEN
1790000950 S.ZEN
D508 1750000370 S.DIO
D509 1750000370 S.DIO
D510 1790001250 S.DIO
1790001250 S.DIO
1790001251 S.DIO
1790001250 S.DIO
1790001250 S.DIO
1790001250 S.DIO
D511 1790001250 S.DIO
1790001250 S.DIO
1790001251 S.DIO
1790001250 S.DIO
1790001250 S.DIO
1790001250 S.DIO
D512 1790001250 S.DIO
1790001250 S.DIO
1790001251 S.DIO
1790001250 S.DIO
1790001250 S.DIO
1790001250 S.DIO
D513 1790001250 S.DIO
1790001250 S.DIO
1790001251 S.DIO
1790001250 S.DIO
1790001250 S.DIO
1790001250 S.DIO
X501 6050012680 S.XTA
L500 6200002861 S.COI
L501 6200003640 S.COI
L502 6200002861 S.COI
R500 7030003810 S.RES ERJ3GEYJ 125 V (1.2M)
R501 7030003810 S.RES ERJ3GEYJ 125 V (1.2M)
R506 7030007290 S.RES ERJ2GEJ 222 X (2.2K)
R507 7030007300 S.RES ERJ2GEJ 332 X (3.3K)
R508 7030007290 S.RES ERJ2GEJ 222 X (2.2K)
R509 7030007300 S.RES ERJ2GEJ 332 X (3.3K)
R510 7030005530 S.RES ERJ2GEJ 100 X (10)
R511 7030005160 S.RES ERJ2GEJ 105 X (1M)
R512 7510001730 S.THE
R513 7030005120 S.RES ERJ2GEJ 102 X (1K)
R514 7030008010 S.RES ERJ2GEJ 123 X (12K)
R515 7030008010 S.RES ERJ2GEJ 123 X (12K)
R516 7030005050 S.RES ERJ2GEJ 103 X (10K)
R517 7030008010 S.RES ERJ2GEJ 123 X (12K)
R518 7410001140 S.ARR EXB28V104JX
R519 7030005090 S.RES ERJ2GEJ 104 X (100K)
R520 7030005090 S.RES ERJ2GEJ 104 X (100K)
R523 7030005710 S.RES ERJ2GEJ 121 X (120)
R524 7030005090 S.RES ERJ2GEJ 104 X (100K)
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
8
DESCRIPTION M.
S1D15206F00A200 B
S-80942CNMC-G9CT2G B
UPD78F1153GK-GAK-AX
(FX3063C-1) B
NJM2870F05-TE1-#FZZB B
CD4053BPWR B
TA75S01F(TE85R,F) B
TDA8547TS/N B
DTC114TUA T106 B
DTC114TUA T106 B
DTC114TUA T106 B
DTC114TUA T106 B
DTC114TUA T106 B
XP6501-(TX).AB B
2SB1132 T100 R B
DTC114TUA T106 B
DTC114TUA T106 B
DTA114TUA T106 B
DTA114TUA T106 B
DTA114TUA T106 B
DTA114TUA T106 B
DTC114TUA T106 B
DTC114TUA T106 B
MA2S077-(TX) [USA-01] B
MA2S077-(TX) [EXP-01]
MA2S077G0L [CHN-02]
MA2S077-(TX) [USA-02]
MA2S077-(TX) [EXP-02]
MA2S077-(TX) [EUR-01]
MA2S111-(TX) [USA-01] B
MA2S111-(TX) [EXP-01]
MA2S1110GL [CHN-02]
MA2S111-(TX) [USA-02]
MA2S111-(TX) [EXP-02]
MA2S111-(TX) [EUR-01]
RB160L-40 TE-25 B
RB160L-40 TE-25 B
MA8056-M(TX) [USA-01] B
MA8056-M(TX) [EXP-01]
MAZ8056GML [CHN-02]
MA8056-M(TX) [USA-02]
MA8056-M(TX) [EXP-02]
MA8056-M(TX) [EUR-01]
DA221 TL B
DA221 TL B
MA2S111-(TX) [USA-01] B
MA2S111-(TX) [EXP-01]
MA2S1110GL [CHN-02]
MA2S111-(TX) [USA-02]
MA2S111-(TX) [EXP-02]
MA2S111-(TX) [EUR-01]
MA2S111-(TX) [USA-01] B
MA2S111-(TX) [EXP-01]
MA2S1110GL [CHN-02]
MA2S111-(TX) [USA-02]
MA2S111-(TX) [EXP-02]
MA2S111-(TX) [EUR-01]
MA2S111-(TX) [USA-01] B
MA2S111-(TX) [EXP-01]
MA2S1110GL [CHN-02]
MA2S111-(TX) [USA-02]
MA2S111-(TX) [EXP-02]
MA2S111-(TX) [EUR-01]
MA2S111-(TX) [USA-01] B
MA2S111-(TX) [EXP-01]
MA2S1110GL [CHN-02]
MA2S111-(TX) [USA-02]
MA2S111-(TX) [EXP-02]
MA2S111-(TX) [EUR-01]
CR-858(SMD-49/18.432 MHz)
<JJE> B
NLV25T-4R7J B
MLF1608E 100K-T B
NLV25T-4R7J B
B
B
B
B
B
B
B
B
ERTJOEP 473J B
B
B
B
B
B
B
B
B
B
B
S.=Surface mount
H/V
LOCATION
69.4/35.9
105.3/24
101.3/38.7
47.2/30.5
39.1/31.7
143/18
28.4/55.8
148.4/41.4
161.8/34.6
161.8/41.4
148.4/34.6
91.4/45.6
32.9/48.1
36.9/52.6
152.8/53.2
166.2/53
168.7/53
160.1/49.6
155.3/53.2
145.3/49.9
160.1/46.9
145.3/47
112.3/33.9
95/45.8
41.8/26.6
63.2/6.6
160.8/29.9
153.2/27.7
166.4/28.1
43.2/51.5
115.8/44.9
65.3/10.2
36.3/24.4
113.1/28.2
106/17.9
161.5/17.9
85.9/39.3
83.5/43.7
87.4/47.5
157.7/36.3
167.9/44.3
167.9/37.7
155.4/44.5
106.8/30.5
105.8/30.5
103.1/48.9
102.2/49.8
113.1/32.2
112.3/35.9
103.2/26.4
110.3/33
106.9/47.1
105.4/48.4
96.1/30.7
114.1/37.6
104.4/48.4
