Icom IC-FR6000 Service Manual Addendum page 11

August 2016
6-7 RECEIVE ADJUSTMENT
(For [#63], [#64], [#65], [#66], [#67], [#68], [#69], [#75], [#76], and [#77])
1) Select an adjustment item using cursor or [↑] / [↓] keys of the PC's keyboard.
2) Set or modify the adjustment value as specifi ed using [←] / [→] keys of the PC's keyboard, and then push the [ENTER] key.
ADJUSTMENT
ADJUSTMENT
CONDITION
1
RECEIVE
SENSITIVITY
2
-Preparation-
3 • Channel:
-Adjustment-
1-26 [L]
(Band center)
1-25 [H], [350 MHz]
• Receiving
4 • Channel:
-Adjustment-
1-27 [L]
(Band low)
1-26 [350 MHz]
For only [L]
• Receiving
and [350 MHz]
5 • Channel:
-Adjustment-
1-28 [L]
(Band high)
1-26 [H]
1-27 [350 MHz]
• Receiving
[L]= Low band, [H]=High band, [350 MHz]=350 MHz band.
† ; The output level of the standard signal generator (SSG) is indicated as the SSG's open circuit.
(Amended page)
OPERATION
– • Set the item [RX Mode] to "1."
Connect the SSG to the RX antenna connec-
tor, and then set to:
†
– Level :
Modulation:
Deviation:
1) Set the SSG to:
Frequency:
2) Select the item [BPF C ALL], and then
push the [ENTER] key.
1) Set the SSG to:
Frequency:
2) Select the item [BPF L ALL], and then
push the [ENTER] key.
1) Set the SSG to:
Frequency:
2) Select the item [BPF H ALL], and then
push the [ENTER] key.
+20 dBμ (–87 dBm)
1 kHz
±3.5 kHz
435.000 MHz [L]
450.100 MHz [H]
375.000 MHz [350 MHz]
400.100 MHz [L]
350.100 MHz [350 MHz]
469.900 MHz [L]
519.900 MHz [H]
399.900 MHz [350 MHz]
6-13
ADJUSTMENT
VALUE
ITEM/POINT
"1"
[RX Mode]
–
[BPF C ALL]
(Automatic
[BPF L ALL]
adjustment)
[BPF H ALL]
–
