Icom IC-FR6000 Service Manual Addendum page 146

May. 2010
SERVICE MANUAL
ADDENDUM
CONTENTS
REPLACEMENT PAGE . . . . . . . . . . . . . . . . . . . . . . . 6-1
PARTS LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
VOLTAGE DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . 18
FREQUENCY
MODEL VERSION
RANGE
USA-01 400–470 MHz
USA-02 450–512 MHz
IC-FR6000 EXP-01 400–470 MHz
EXP-02 450–520 MHz
EXP-03 400–470 MHz
IC-FR6000-L CHN-01 350–400 MHz
EUR-01
IC-FR6100 400–470 MHz
DPM-01
CHANNEL TX
SPACING POWER
6.25/12.5/25.0 kHz
12.5/25.0 kHz 50 W
6.25/12.5/25.0 kHz
12.5/20.0/25.0 kHz
25 W
6.25/12.5/20.0/25.0
