Icom IC-FR6000 Service Manual Addendum page 240

Feb. 2009
SERVICE MANUAL
ADDENDUM
CONTENTS
REPLACEMENT PAGES . . . . . . . . . . . . . . . . . . . . . . 6-1 to 6-10
PARTS LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
VOLTAGE DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . 11
FREQUENCY
MODEL VERSION
USA-01 400–470 MHz 6.25/12.5/25.0
USA-02 450–520 MHz
IC-FR6000 EXP-01 400–470 MHz
EXP-02 450–520 MHz
CHN-02 400–470 MHz 6.25/12.5/25.0
IC-FR6000-L CHN-01 350–400 MHz
IC-FR6100 EUR-01 400–470 MHz
CH. SPACING
RANGE POWER
kHz
12.5/25.0 kHz 50 W
kHz
12.5/20.0/25.0
25 W
kHz
TX
