CAPA55R Capa Board
2.4

Installing M.2 2230 Key E and M.2 2280 Key M

Image below illustrates how to install M.2 2230 Key E (CN10) and M.2 2280 Key M (CN6).
M.2 2230 Key E card only:
M.2 2280 Key M card only:
M.2 2230 Key E card + M.2 2280 Key M card:
Board and Pin Assignments 13
