Goodrive800 Pro Series Inverter Unit Hardware Manual
4.4.1.2 Main circuit wiring terminals
Name
(+), (-)
U, V, W
PE
4.4.1.3 Screw tightening
202202 (V1.0)
Figure 4-10 Terminals of an inverter module in the A8i frame
DC bus voltage input terminals
3PH AC output terminals
Grounding terminal
Figure 4-11 Screw installation requirements
NG
The screw is
not fastened.
Description
Y
The screw is
fastened.
Electrical installation
44
