To ensure good heat dissipation of the inverter unit, design the air inlet and outlet as follows:
Air inlet area formula: S
S: System ventilation area
S : Each module ventilation area (cm
module
Air outlet area formula: S
For details about the air volume required by the units, see Table 3-1.
No.
1
2
3

3.3.5.2 Cabinet requirements
It is recommended that the cabinet adopts the nine-fold profile cabinet (PS cabinet). Before installing the
inverter unit, install two bottom support crossbeams, an installation bracket, and an installation rail in the
cabinet, and design the installation crossbeam for inverter unit fixing, and reserve fixing holes on the
installation crossbeam (see Appendix B for the specific location and size).
Fix the bottom support crossbeams and installation bracket. See Figure 3-11.
202202 (V1.0)
Figure 3-10 Installation space requirements
≥20 ≥6
Front view
=(1.5~2.0) x (S
in module1+
=(1.2~1.5) x S
out in
Table 3-1 Ventilation areas and actual air volumes of inverter units
Frame size
A8i
2*A8i
3*A8i
Violation of the requirements in 3.3.5.1 Installation space and heat dissipation will
shorten the inverter unit life and may result in inverter unit failure or malfunction.
≥20
≥20
Air inlet
Side view
S + S +......+ S
module2 module3
)
2
Ventilation area S (cm
in
982
1964
2946
Mechanical installation
Air outlet
≥20
Sealing sponge
(preventing hot air from
circuilating back)
Air inlet
)
module N
) Actual air volume (CFM)
2
882
1764
2646
