Goodrive800 Pro Series Inverter Unit Hardware Manual
Category Terminal
function
RO1A
RO1B
RO1C
RO2A
RO2B
RO2C
Relay
output
RO3A
RO3B
RO3C
RO4A
RO4B
RO4C
485+
Communi-
cation
485-
202202 (V1.0)
Name
H2 Safety input 2
NO contact of relay 1
NC contact of relay 1
Common contact of
relay 1
NO contact of relay 2
NC contact of relay 2
Common contact of
relay 2
NO contact of relay 3
NC contact of relay 3
Common contact of
relay 3
NO contact of relay 4
NC contact of relay 4
Common contact of
relay 4
RS485 communication
Description
input is required, remove the jumpers between H1
and COM and between H2 and COM.
1. Contact capacity: AC250V/3A, DC30V/1A
2. Cannot be used as high frequency digital output
Note: If any input of STO functions H1 and H2 is
valid, RO4 is forced to output, which can be
used as a regular relay usually.
RS485 communication terminals, using the
Modbus protocol
You can determine whether to connect a 120Ω
terminal resistor through J5.
Inverter Control Unit (ICU)
