Altronix NetWaySP2P Series 3-Port PoE+ hardened switches convert a single Fiber (1000Base-X/SX/LX) into
two (2) Ethernet ports (10/100/1000 Mbps) and provide PoE/PoE+ power to connected devices. Mounted in
variety of housing to accommodate different environments, they features auto detection and protection of legacy
non-PoE cameras/devices.
Agency Listings:
• CE European Conformity.
Input:
NetWaySP2P/NetWaySP2PWPN:
• 48-56VDC @ 1.9A (95W).
* See below for recommended
Power Sourcing Equipment.
NetWaySP2PWP/NetWaySP2PWPX:
• 115VAC, 60Hz, 2.5A or 230VAC, 50/60Hz, 1.3A.
Fiber Port:
• One (1) 1Gb SFP port.
*See pg. 5 for recommended SFP modules.
Output Power:
• Two (2) PoE / PoE+ ports, rated up to 30W max.
• IEEE 802.3af and IEEE 802.3at compliant.
Ethernet:
• IEEE 802.3af (15W) and
IEEE 802.3at (30W) compliant.
• Wire type: 4-pair CAT5e and higher.
• Connectivity: RJ45, auto-crossover.
• Speed: 10/100/1000 Mbps.
• Distance: up to 100m.
Environmental:
• Refer to Environmental Conditions on page 8.

*Recommended Altronix Power Sourcing Equipment:

NetWaySP4P
Ethernet to Fiber Media Converter with Integral Power Supply/Charger.
Four (4) 56VDC non power-limited outputs up to 120W max. full power per port
(240W total power). Four (4) 1Gb SFP ports.
NetWaySP4PX Ethernet to Fiber Media Converter with Integral Power Supply/Charger.
Four (4) 56VDC non power-limited outputs up to 120W max. full power per port
(480W total power). Four (4) 1Gb SFP ports.
NetWaySP4P2 Ethernet to Fiber Media Converter with Integral Power-Limited Power Supply/Charger.
Four (4) 56VDC power-limited outputs up to 60W max. full power per port
(240W total power). Four (4) 1Gb SFP ports.
WayPoint562
High Current Outdoor Power Supply/Charger.
56VDC/120W output.
Filtered and electronically regulated output. Short circuit and thermal overload protection.
Vertiline563
EIA 19" 1U Rack Mountable Dual Independent Power Supply/Charger.
56VDC @ 3A each output.
Filtered and electronically regulated output. Short circuit and thermal overload protection.
PoE201 Power Supply/Charger Board,
Filtered and electronically regulated output. Short circuit and thermal overload protection.
NetWaySP2P Series Installation Guide

Overview:

Features:

LED Indicators
• Yellow and Green LEDs (RJ45 jacks):
IP Link status, 10/100/1000 Base-T/active.
• Green PoE LEDs: Indicate PoE present.
• Green SFP (Fiber) LED: Indicates SFP connection.
Mechanical:
NetWaySP2P:
• Modular plastic case
• Dimensions (H x W x D approx.):
3.375" x 3.8" x 1" (85.7mm x 96.5mm x 25.4mm).
NetWaySP2PWPN:
• NEMA4/4X, IP66 Rated enclosure for outdoor use.
• Dimensions (H x W x D approx.):
9.5" x 7.32" x 4.92"
(241.3mm x 185.9mm x 125mm)
NetWaySP2PWP:
• NEMA4/4X, IP66 Rated enclosure for outdoor use.
• Dimensions (H x W x D approx.):
13.31" x 11.31" x 5.59"
(338.1mm x 287.3mm x 142mm).
NetWaySP2PWPX:
• NEMA4/4X, IP66 Rated enclosure for outdoor use.
• Accommodates four (4) 12VDC/4AH batteries
(48V of backup).
• Dimensions (H x W x D approx.):
17.53" x 15.3" x 6.67"
(445.3mm x 388.6mm x 169.4mm).
56VDC/120W output.
(Refer to Fig. 1, Pg. 5)
:
