Mechanical Drawing and Dimensions (H x W x D approx.):
9.5" x 7.32" x 4.92" (241.3mm x 185.9mm x 125mm)
1.38"
7.32" (185.9mm)
3.54" (89.9mm)
(35.1mm)
316 Stainless Steel
Padlock Latch Attached
0.375" (9.5mm)
Padlock Eye
6.75" (171.5mm)
6.0" (152.4mm)
4.25" (108mm)
304 Stainless Steel Piano Hinge
0.312" (7.9mm) TYP
4 Places
4.0" (101.6mm)
10-32 X 0.25" (6.4mm)
4 Places
- 10 -
NetWaySP2P Series Installation Guide
