NetWay4ES is a 4-Port PoE/PoE+ switch which is designed for installation at the IDF (Intermediate Distribution
Frame) . NetWay4ES allows for system expansion by accommodating up to four (4) IP cameras/devices over
a single CAT-5e or higher structured cable . Power up to 60W is provided by NetWay1D midspan injector
(included in NetWay4ESK Kit), or 30W by NetWay midspan/endspan, or any IEEE 802 .3at standard midspan/
endspan typically located at the MDF (Main Distribution Frame) .
Agency Listings:
• UL 60950-1 Information Technology Equipment .
• CE European Conformity .
Input:
• Up to 60W is provided by NetWay1D midspan
injector or 30W by NetWay midspan/endspan or
any IEEE 802 .3at standard midspan/endspan .
Power Output:
• Maximum power per port: PoE+ (30W) .
• Total maximum power:
NetWay4ES - PoE+ (30W) .
NetWay4ESK - 60W from Netway1D .
Ethernet:
• Connectivity: RJ45, auto-crossover .
• Wire type: 4-pair CAT5e or higher
structured cable .
• Distance: up to 100m .
• Speed: 10/100BaseT, half/full duplex,
auto negotiation .
LED Indicators:
• Yellow - IP Link status,
Green - 10/100Base-T/active .
Wiring methods shall be in accordance with the National Electrical Code/NFPA 70/ANSI, and with all local
codes and authorities having jurisdiction . Wiring should be UL Listed and/or Recognized wire suitable for the
application . Midspan or endspan and NetWay4ES/NetWay4ESK is not intended to be connected to outside
plant leads and should be installed indoors within the protected premises . The midspan or endspan injector and
NetWay4ES/NetWay4ESK are intended for indoor use only .
1 . Midspan or Endspan installation: Please refer to the corresponding installation instructions .
2 . NetWay1D installation (Fig. 1, pg. 4):
a . Affix rubber pads to NetWay1D for shelf installation (Fig. 4, pg. 8) .
b . Plug the grounded AC line cord (included) into the IEC 320 connector of the NetWay1D unit .
Plug unit into a reliable earth grounded socket .
When using multiple units the sum of the individual name plate ratings should not exceed the supply
circuit rating .
Note: Do not connect to a receptacle controlled by a switch.
c . Connect structured cable from UL Listed ethernet switch or video server to RJ45 jack marked [IN] on
NetWay1D (Fig. 2, pg. 6) .
3 . NetWay4ES installation:
a . Mounting: Affix rubber pads to NetWay4ES for shelf installation (Fig. 4, pg. 8) .
b . Connect structured cable from NetWay4ES to RJ45 jack marked [OUT] to NetWay1D (Fig. 2, pg. 6) or
midspan or endspan (Fig. 1, pg. 5) .
c . PoE ON LED of the NetWay1D will illuminate indicating PoE device is turned on (Fig. 2, pg. 6) .
d . Connect IP cameras/devices to RJ45 jacks marked [1-4 PoE Output 10/100BaseT] (Figs. 1, 2, pgs. 5, 6) .
NetWay4ES / NetWay4ESK

Overview:

Features:

Installation Instructions:

Environmental:
• Operating Ambient Temperature:
NetWay1D: 30W: -30ºC to 50ºC (-22ºF to 122ºF) .
60W: -30ºC to 40ºC (-22ºF to 104ºF) .
NetWay4ES: 60W: -40ºC to 75ºC (-40ºF to 167ºF) .
• Storage Temperature:
NetWay1D: -30ºC to 85ºC (-22ºF to 185ºF) .
NetWay4ES: -40ºC to 75ºC (-40ºF to 167ºF) .
• Humidity: 20 to 85%, non-condensing .
Applications:
• Remote installation and powering of a
4-port PoE+ switch .
Star expansion of remote node to 4-PoE+
cameras/devices .
Mechanical:
• Dimensions (H x W x D approx .):
NetWay1D: 1 .75" x 4 .125" x 7 .25"
(44 .4mm x 104 .8mm x 184 .1mm) .
NetWay4ES: 1 .7" x 5 .23" x 8 .42"
(43 .18mm x 132 .8mm x 213 .9mm) .
