Altronix NetWay2ES and NetWay2ESWPN are PoE-powered 2 port PoE/PoE+ switches and are designed for instal-
lation at the IDF (Intermediate Distribution Frame) to deploy IP devices . NetWay2ES allows for system expansion by
accommodating up to two (2) IP cameras/devices over a single CAT5 or higher structured cable . PoE is passed from
a midspan injector, typically located at the MDF (Main Distribution Frame) .
Agency Listings:
• CE European Conformity .
Ethernet Input:
• 802 .3bt PoE up to 90W or 802 .3at up to 30W or
802 .3af up to 15W is provided by
PoE midspan/endspan .
• IEEE 802 .3bt compliant .
Output:
• IEEE 802 .3af (15 .4W),
IEEE 802 .3at (30W) compliant .
Ports:
• Connectivity: RJ45, auto-crossover .
• Wire type: 4-pair CAT5e and higher .
• Speed: 10/100 Mbps .
• Distance: up to 100m .
Wiring methods shall be in accordance with the National Electrical Code/NFPA 70/ANSI, and with all local codes
and authorities having jurisdiction . All units should be installed by a trained service personnel .

Installation:

NetWay2ES:
1 . Mount NetWay2ES in desired location utilizing the mounting hole (Fig. 1a, pg. 4) . Use a proper fastener
and/or wall anchor when securing NetWay2ES with screw through its mounting hole to the surface .
Note: Earth ground can be used, if needed, for high transient or outdoor environments. If used,
insert an Earth ground wire (included with product) into the internal ground terminal until secured
(a slight tug can check stability) & fasten the free end to a chassis earth ground (Fig. 3, pg. 4).
NetWay2ESWPN:
2 . Remove backplane from enclosure prior to drilling . Do not discard hardware .
Note: Make sure that hardware will not interfere with components of the circuit board .
3 . Mark and drill desired inlets on the enclosure to facilitate wiring. Maximum NEMA type 4X rated fittings
to be used are 0 .5" . Follow manufacturer's specifications for the appropriate size opening .
Note: Inlets for conduit fittings should only be made on the bottom of the enclosure .
To facilitate wire entry utilize weather-tight NEMA rated connectors (supplied), bushings, and cable .
4 . Clean out the inside of enclosure before remounting circuit boards/backplane .
5 . Mounting NEMA4/4X rated enclosure (Enclosure Dimensions, pg. 7):
Wall mount:
Pole Mount:
6 . Mount backplane in enclosure with hardware .
NetWay2ES Series

Installation Instructions:

Mount unit in desired location . Mark and drill holes to line up with the top and bottom
hole of the enclosure flange . Secure enclosure with appropriate fasteners (e . g . screws
and anchors; bolts and locking nuts, etc .) that are compatible with mounting surface and
are of sufficient length/construction to ensure a secure mount (Fig. 5, pg. 6) .
Refer to Fig. 6 - 10, pg. 6 .

Overview:

Features:

Environmental:
• Refer to Environmental Conditions on page 5.
LED Indicators
• Yellow and Green LEDs (RJ45 jacks):
IP Link status, 10/100Base-T/active .
• Green PoE LEDs:
Indicate PoE present .
Mechanical:
NetWay2ES:
• Modular plastic case .
3 .375" x 3 .8" x 1" (85 .7mm x 96 .5mm x 25 .4mm) .
NetWay2ESWPN:
• NEMA4/4X, IP66 Rated enclosure for outdoor use .
• Dimensions (H x W x D approx .):
9 .5" x 7 .32" x 4 .92"
(241 .3mm x 185 .9mm x 125mm)
(Refer to Fig. 3, Pg. 4)
:
