Altronix HubWayEX16/EX32 Active UTP Transceiver Hub employs automatic gain control (AGC) to transmit
UTP video, RS422/RS485 data over a single CAT-5 or higher structured cable . Units provide either 16 or 32
camera channels in a space saving 1U EIA 19" rack mount chassis which may be rack, wall or shelf mounted .
Video transmission range is up to one mile max . per channel . Units are compatible with fixed or PTZ cameras .
Each grouped camera channel provides video transmission for up to four (4) cameras over a single CAT-5 or
higher structured cable . This permits the installation of up to sixteen (16) cameras at remote locations over four
(4) CAT-5 or higher structured cables or thirty-two (32) cameras at remote locations over eight (8) CAT-5 or
higher structured cables .
HubWayEX16
Input:
• 115VAC, 60Hz, 0 .4A or 230VAC, 50Hz, 0 .2A .
Video:
• Sixteen (16) channels of video over twisted pair
up to a distance of 5,000 ft . per channel .
• Sixteen (16) 75 ohm video outputs .
Data:
• RS422/RS485 data inputs .
Visual Indicators:
• AC input power indicator .
• Video signal and power LED indicators .
Features:
• Automatic picture and gain control .
• Automatic compensation for
reverse polarity wiring (video) .
• Illuminated master power disconnect
circuit breaker with manual reset .
WARNING: To reduce the risk of fire or electric shock do not expose the unit to rain or moisture.
This installation should be made by qualified service personnel and should conform to all local codes.
HubWayEX16/EX32

Overview:

HubWayEX Specifications:

Specifications:

HubWayEX32
Input:
• 115VAC, 60Hz, 0 .4A or 230VAC, 50Hz, 0 .2A .
Video:
• Thirty-two (32) channels of video over twisted pair
up to a distance of 5,000 ft . per channel .
• Thirty-two (32) 75 ohm video outputs .
Features (cont'd):
• IEC 320 - 3-wire grounded line cord (detachable) .
• Unit can be rack, wall or shelf mounted .
• 1U rack mount chassis for use in standard
EIA 19" rack .
Accessories:
• Optional HubSat4D/Di or HubWayEXP allows
transmission of up to four (4) video signals over a
single CAT-5 or higher structured cable .
- 3 -
