ENGLISH
6.6

OPTIONAL

6.6.1

Digital pressure switch

ATTENTION: The pressure switch is delivered with a default
password 4602 . Upon the first start it is necessary to change
the password selecting it between the value 4001 and 9999.
Digital pressure switch description:
Display of pressure in psi;
Display of pressure in Mpa;
Display of pressure in bar;
Button for changing the unit of measurement
Button for displaying of the partial hours
Button for return to the menu or reset
Confirmation button
Selection buttons
Entering of the password
The password consists of 4 numbers.
Enter the first digit by pressing the keys
the desired value, then press
show the second, third and fourth digits in sequence.
Enter the fourth digit by pressing
possible to modify the individual parameters of the main menu. Press the
key
to return to the menu without saving.
How to view and reset the partial hours of
operation
Press the key
To reset the value, when the indication of the partial hours appears on the
display, keep the key pressed
Pressure measurement unit selection
Press the key
, MPa, bar lights up.
38 - 60
to move to the next digit. The display will
. The password will be saved. It will be
to display the partial hours:
until reset (0000).
until the LED near the words psi
ERGO ELECTRIC
ITALIANO
6.6
OPTIONAL
6.6.1

Pressostato digitale

ATTENZIONE: Il pressostato viene consegnato con una
password di default 4602. Al primo avviamento è obbligatorio
cambiare la password selezionandola tra il valore 4001 e
9999.
Descrizione pressostato digitale:
Visualizzazione della pressione in psi;
Visualizzazione della pressione in Mpa;
Visualizzazione della pressione in bar;
Pulsante per il cambio dell'unità di misura
Pulsante per la visualizzazione delle ore parziali
Pulsante di ritorno al menu o reset
Pulsante di conferma
Pulsanti selezione
to
al valore desiderato, poi premere
display mostrerà in sequenza la seconda, la terza e la quarta cifra.
Inserita la quarta cifra, premendo
possibile modificare i singoli parametri del menu principale. Premere il
tasto
per tornare al menu senza salvare.
Per resettare il valore, quando sul display compare l'indicazione delle ore
parziali, tenere premuto il tasto
illumina.
Inserimento della password
La password è composta da 4 numeri.
Inserire la prima cifra premendo i tasti
per passare alla cifra successiva. Il
, la password verrà salvata, sarà
Come visualizzare e resettare le ore parziali di
funzionamento
Premere il tasto
per visualizzare le ore parziali.
fino all'azzeramento (0000).
Selezione unità di misura della pressione
Premere il tasto
fino a quando il led in
corrispondenza delle scritte psi, MPa, bar si
fino
MU-ERGO-0820
