6 | Technical data
Service manual
318
English
Space C/H On/OFF output
SWB
(6) Options
Continuous
DHW pump output
Electric pulse meter input: 12 V DC
pulse detection (voltage supplied by
PCB)
Ext. ambient sensor option (indoor or
outdoor)
For cooling mode
For HP tariff
For HV smartgrid
For LV smartgrid
For safety thermostat
For smartgrid
Inrush
Max. load
MMI
NO valve
Only for ***
Preferential kWh rate power supply
contact: 16 V DC detection (voltage
supplied by PCB)
Remote user interface
Safety thermostat contact: 16 V DC
detection (voltage supplied by PCB)
SD card
Smartgrid contacts
Smartgrid PV power pulse meter
SWB1
SWB2
WLAN cartridge
(7) External On/OFF thermostats and
heat pump convector
Additional LWT zone
Main LWT zone
Translation
Space cooling/heating ON/OFF output
Hydro switch box 1 (front side)
(6) Options
Continuous current
Domestic hot water pump output
Electricity meter pulse input: 12 V DC
pulse detection (voltage supplied by
PCB)
External indoor or outdoor ambient
thermistor
For cooling mode
For preferential kWh rate power supply
For high voltage Smart Grid
For low voltage Smart Grid
For safety thermostat
For Smart Grid
Inrush current
Maximum load
Standalone user interface (delivered as
accessory)
Normal open valve
Only for ***
Preferential kWh rate power supply
contact: 16 V DC detection (voltage
supplied by PCB)
Dedicated Human Comfort Interface
(BRC1HHDA used as room thermostat)
Safety thermostat contact: 16 V DC
detection (voltage supplied by PCB)
Card slot for WLAN cartridge
Smart Grid contacts
Smart Grid photovoltaic power pulse
meter
Hydro switch box 1 (front side)
Hydro switch box 2 (right side)
WLAN cartridge
(7) External ON/OFF thermostats and
heat pump convector
Additional leaving water temperature
zone
Main leaving water temperature zone
EBLA09~16DA + EDLA09~16DA
Daikin Altherma 3 M
ESIE20-06A – 2021.03
