Page 1 Installer reference guide Daikin Altherma 3 M https://daikintechnicaldatahub.eu EBLA04E2V3 EDLA04E2V3 EBLA06E2V3 EDLA06E2V3 EBLA08E2V3 EDLA08E2V3 EBLA04E23V3 EDLA04E23V3 EBLA06E23V3 EDLA06E23V3 EBLA08E23V3 EDLA08E23V3...
Page 2: Table Of Contents
Opening and closing the unit............................68 7.3.1 About opening the units..........................68 7.3.2 To open the outdoor unit..........................68 7.3.3 To rotate the switch box ..........................69 Installer reference guide EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 3 2-points curve..............................145 11.5.3 Slope-offset curve............................146 11.5.4 Using weather-dependent curves........................148 11.6 Settings menu ................................. 150 11.6.1 Malfunctioning ............................... 150 11.6.2 Room................................150 11.6.3 Main zone ............................... 155 EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 4 17.1 Piping diagram: Outdoor unit ............................254 17.2 Wiring diagram: Outdoor unit ............................256 17.3 ESP curve: Outdoor unit ..............................265 18 Glossary 19 Field settings table Installer reference guide EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 5: About This Document
The original documentation is written in English. All other languages are translations. Technical engineering data ▪ A subset of the latest technical data is available on the regional Daikin website (publicly accessible). ▪ The full set of latest technical data is available on the Daikin Business Portal (authentication required).
Page 6: Meaning Of Warnings And Symbols
WARNING: FLAMMABLE MATERIAL CAUTION Indicates a situation that could result in minor or moderate injury. NOTICE Indicates a situation that could result in equipment or property damage. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 7: Installer Reference Guide At A Glance
Electrical installation What to do and know to install the electrical components of the system, including information on how to prepare for an installation EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 8 Note: There is also an installer settings table in the user reference guide. This table has to be filled in by the installer and handed over to the user. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 9: General Safety Precautions
Improper installation or attachment of equipment or accessories could result in electrical shock, short-circuit, leaks, fire or other damage to the equipment. ONLY use accessories, optional equipment and spare parts made or approved by Daikin. WARNING Make sure installation, testing and applied materials comply with applicable legislation (on top of the instructions described in the Daikin documentation).
Page 10: Installation Site
Make sure the field piping and connections are NOT subjected to stress. WARNING During tests, NEVER pressurise the product with a pressure higher than the maximum allowable pressure (as indicated on the nameplate of the unit). EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 11 ONLY use tools exclusively for the refrigerant type used in the system, this to ensure pressure resistance and prevent foreign materials from entering into the system. ▪ Charge the liquid refrigerant as follows: EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 12: Water
If NOT factory installed, a main switch or other means for disconnection, having a contact separation in all poles providing full disconnection under overvoltage category III condition, MUST be installed in the fixed wiring. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 13 Install power cables at least 1 meter away from televisions or radios to prevent interference. Depending on the radio waves, a distance of 1 meter may NOT be sufficient. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 14 ON and OFF while the product is operating, attach a reversed phase protection circuit locally. Running the product in reversed phase can break the compressor and other parts. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 15: Specific Installer Safety Instructions
WARNING Make sure installation, servicing, maintenance and repair comply with instructions from Daikin and with applicable legislation and are executed ONLY by authorised persons. Mounting the outdoor unit (see "7.2 Mounting the outdoor unit" [...
Page 16 To guarantee the unit is completely earthed, ALWAYS connect the backup heater power supply and the earth cable. WARNING Stripped wire. Make sure that stripped wire cannot make contact with possible water on the bottom plate. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 17 Specific installer safety instructions "12 Commissioning" [ 224]) Commissioning (see WARNING Commissioning method MUST be in accordance with the instructions from this manual. See "12 Commissioning" [ 224]. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 18: About The Box
1 Cut straps and remove the cardbord. 2 Remove the top packaging. 4.1.2 To remove the accessories from the outdoor unit 1 Remove the accessories on top and in front of the unit. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 19 Bolts, nuts, washers, and spring washers 2 After opening the unit (see "7.3.2 To open the outdoor unit" [ 68]), remove the accessory inside the unit. m Shutoff valve EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 20: About The Units And Options
Low water temperature – ambient zone 2 (see operation range) Refrigerant R32 Capacity class Model series 3=Model with integrated backup heater [—]=Model without integrated backup heater Power supply: V3=1N~, 230 V AC, 50 Hz EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 21: Combining Units And Options
(BRC1HHDA used as room thermostat) will be used as room temperature sensor. As an option the remote indoor sensor can be installed to measure the room temperature on another location. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 22 If you install the external backup heater kit, then under certain conditions you also need to install a bypass valve kit (EKMBHBP1). See: EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 23 Components to comply with the UK Building Regulation G3. ▪ EKHWSU200D3V3 For these tanks an optional domestic ▪ EKHWSU250D3V3 hot water tank thermistor with 30 m ▪ EKHWSU300D3V3 cable length (EKTESE1) is available. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 24 For installation instructions, see the installation manual of the LAN adapter. LAN adapter for smartphone control + Smart Grid applications (BRP069A61) You can install this LAN adapter to: EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 25: Possible Combinations Of Outdoor Unit And Domestic Hot Water Tank
Use EKHY3PART2. a Outdoor unit b Tank For more detailed installation instructions, see the installation manual of the connection kit and the addendum book for optional equipment. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 26: Application Guidelines
Setting up the domestic hot water tank ▪ Setting up the energy metering ▪ Setting up the power consumption control ▪ Setting up an external temperature sensor EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 27: Setting Up The Space Heating/Cooling System
SH normal/DHW off NOTICE An overpressure bypass valve can be integrated in the system. Keep in mind that this valve might not be shown on the illustrations. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 28: Single Room
For your daily needs, you can use preset values and schedules. To deviate from your daily needs, you can temporarily overrule the preset values and schedules, or use the holiday mode. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 29 Code: [C-05] heating or cooling demand. Benefits ▪ Wireless. The Daikin external room thermostat is available in a wireless version. ▪ Efficiency. Although the external room thermostat only sends ON/OFF signals, it is specifically designed for the heat pump system. ▪...
Page 30 Benefits ▪ Cooling. The heat pump convector offers, besides heating capacity, also excellent cooling capacity. ▪ Efficiency. Optimal energy efficiency because of the interlink function. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 31 The shut-off valve Configuration Setting Value Unit temperature control: 1 (External room thermostat): Unit operation is decided by the ▪ #: [2.9] external thermostat. ▪ Code: [C-07] EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 32: Multiple Rooms - One Lwt Zone
Dedicated Human Comfort Interface (BRC1HHDA used as room thermostat) ▪ For more information about connecting the electrical wiring to the unit, see "9.2 Connections to the outdoor unit" [ 90]. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 33 To guarantee reliable operation, provide a minimum water flow as described in table "To check the water volume and flow rate" in "8.1 Preparing water piping" [ 71]. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 34 The installation manual of the heat pump convector options The addendum book for optional equipment ▪ The user interface connected to the outdoor unit decides the space operation mode. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 35 For each room with heat pump convectors: The heat pump convectors are directly connected to the outdoor unit – or to the external backup heater kit, if there is one. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 36: Multiple Rooms - Two Lwt Zones
If there is more than one leaving water zone, ALWAYS install a mixing valve station in the main zone to decrease (in heating)/increase (in cooling) the leaving water temperature when the additional zone has demand. Typical example: EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 37 System without hydraulic separator: System with hydraulic separator for main zone: System with hydraulic separator for both zones: For this system, a direct pump is required for the additional zone. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 38 (X2M/35a and X2M/30). The outdoor unit will only supply the desired additional leaving water temperature when there is an actual demand. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 39 If the main zone must be shut off during cooling mode to prevent condensation on the floor, set it accordingly. "Bizone kit" [ 216] for more information on configuration of the bizone kit. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 40: Setting Up An Auxiliary Heat Source For Space Heating
During heating operation of the auxiliary boiler, the auxiliary boiler operates to achieve the desired water temperature set via the auxiliary boiler controller. Setup ▪ Integrate the auxiliary boiler as follows: EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 41 Make sure the auxiliary boiler and its integration in the system complies with applicable legislation. ▪ Daikin is NOT responsible for incorrect or unsafe situations in the auxiliary boiler system. ▪ Make sure the return water to the heat pump does NOT exceed 60°C. To do so: Set the desired water temperature via the auxiliary boiler controller to maximum 60°C.
Page 42 To prevent freeze-up of the water piping, the auxiliary gas boiler must have a fixed setpoint ≥55°C, or a weather-dependent setpoint ≥T (°C) –30 –25 –20 –15 –10 –5 (°C) Outdoor temperature Minimum weather-dependent setpoint for auxiliary gas boiler EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 43: Setting Up The Domestic Hot Water Tank
Example: If the DHW consumption of a family (4 persons) per day is as follows: ▪ 3 showers ▪ 1 bath ▪ 3 sink volumes Then the DHW consumption = (3×100 l)+(1×150 l)+(3×10 l)=480 l EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 44 DHW tank during the day. If energy prices are lower during the night, we recommend to heat up the DHW tank during the night. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 45: Setup And Configuration - Dhw Tank
For polypropylene tanks (EKHWP*), the booster heater option (EKBH3S) must be installed. 6.4.4 DHW pump for instant hot water INFORMATION This topic shows an application example in case of stainless steel tanks (EKHWS*D*). EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 46: Dhw Pump For Disinfection
6.4.5 DHW pump for disinfection INFORMATION Restriction: Only applicable in case of stainless steel tanks (EKHWS*D*). Setup a DHW tank EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 47: Dhw Pump For Tank Preheating
For the electrical wiring, see "9.2.8 To connect the domestic hot water pump" [ 112]. Configuration The outdoor unit can control DHW pump operation. For more information, see "11 Configuration" [ 123]. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 48: Setting Up The Energy Metering
If you measure a booster heater resistance of 17.1Ω, the capacity of the heater at 230 V is 3100 W. 6.5.2 Consumed energy You can use the following methods to determine the consumed energy: ▪ Calculating ▪ Measuring EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 49: Power Supply Layouts With Power Meters
Single-phase power meter in other cases. 2 power meters. You need 2 power meters in case of preferential kWh rate power supply WITH separate normal kWh rate power supply. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 50 The power meter cannot easily be installed in the electrical cabinet. 230 V and 400 V three-phase grids are combined (very uncommon), because of technical limitations of power meters. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 51 C External backup heater kit a Electrical cabinet: Normal kWh rate power supply b Power meter c Overcurrent fuse d Compressor module e Hydro module f Backup heater g Booster heater EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 52 Electrical cabinet: Preferential kWh rate power supply b Power meter c Overcurrent fuse d Compressor module e Hydro module f Backup heater g Booster heater S1S Preferential kWh rate power supply contact EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 53 Power meter 1 b2 Power meter 2 c Overcurrent fuse d Compressor module e Hydro module f Backup heater g Booster heater S1S Preferential kWh rate power supply contact EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 54: Setting Up The Power Consumption Control
Permanent power limitation is useful to assure a maximum power or current input of the system. In some countries, legislation limits the maximum power consumption for space heating and DHW production. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 55: Power Limitation Activated By Digital Inputs
6.6.2 Power limitation activated by digital inputs Power limitation is also useful in combination with an energy management system. The power or current of the entire Daikin system is limited dynamically by digital inputs (maximum four steps). Each power limitation level is set via the user interface by limiting one of the following: ▪...
Page 56: Power Limitation Process
Then set the priority heater via the user interface to… Domestic hot water production Booster heater (if applicable) Result: The backup heater will be turned OFF first. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 57: Bbr16 Power Limitation
(Swedish energy regulations). You can combine the BBR16 power limitation with the other kW power consumption controls. If you do so, the unit uses the most restrictive control. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 58: Setting Up An External Temperature Sensor
At the north side of the house or at the side of the house where the most heat emitters are located That is NOT exposed to direct sunlight ▪ If this is NOT possible, we recommend to connect a remote outdoor sensor (option EKRSCA1). EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 59 To protect the outdoor unit, the internal sensor of the outdoor unit is always used. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 60: Unit Installation
Also read the precautions and requirements in the "2 General safety precautions" [ 9]. Mind the following spacing guidelines: > > ≥500 >250 (mm) (mm) > >350 (mm) EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 61 It is NOT recommended to install the unit in the following places because it may shorten the life of the unit: ▪ Where the voltage fluctuates a lot ▪ In vehicles or vessels ▪ Where acidic or alkaline vapour is present EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 62 Precise water piping length can be determined using the Hydronic Piping Calculation tool. The Hydronic Piping Calculation tool is part of the Heating Solutions Navigator which can be reached via https://professional.standbyme.daikin.eu. Please contact your dealer if you have no access to Heating Solutions Navigator.
Page 63: Additional Installation Site Requirements Of The Outdoor Unit In Cold Climates
In any case, provide at least 300 mm of free space below the unit. Additionally, make sure the unit is positioned at least 100 mm above the maximum expected level of snow. See "7.2 Mounting the outdoor unit" [ 64] for more details. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 64: Mounting The Outdoor Unit
Additionally, make sure the unit is positioned at least 100 mm above the maximum expected level of snow. INFORMATION The maximum height of the upper protruding part of the bolts is 15 mm. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 65: To Install The Outdoor Unit
1 Carry the unit using the slings attached to the unit. Pull up both sides of the sling at the same time to prevent disconnection of the sling from the unit. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 66 ▪ (1) Put the unit into position. ▪ (2) Remove the slings (by pulling 1 side of the sling). ▪ (3) Fix the unit. 2× a Air outlet EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 67: To Provide Drainage
If the unit CANNOT be installed fully level, always make sure that the inclination is towards the backside of the unit. This is required to guarantee proper drainage. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 68: To Prevent The Outdoor Unit From Falling Over
DANGER: RISK OF ELECTROCUTION Do NOT leave the unit unattended when the service cover is removed. 7.3.2 To open the outdoor unit DANGER: RISK OF ELECTROCUTION DANGER: RISK OF BURNING/SCALDING EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 69: To Rotate The Switch Box
1 Push down the clip of the switch box holder. 2 Rotate the switch box out of the unit. 3 Rotate the switch box back until it engages properly in the switch box holder. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 70: To Close The Outdoor Unit
NOTICE Speed nut. Make sure the speed nut for the top screw is correctly attached to the service cover. 3.55 N . m 5× a Speed nut EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 71: Piping Installation
Because brass is a soft material, use appropriate tooling for connecting the water circuit. Inappropriate tooling will cause damage to the pipes. ▪ Freeze. Protect against freezing. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 72 For the external static pressure curves of the outdoor unit, see the technical data. A subset of the latest technical data is available on the regional Daikin website (publicly accessible). The full set of latest technical data is available on the Daikin Business Portal (authentication required).
Page 73 Domestic hot water tank – Standstills. In cases where during longer periods of time there is no consumption of hot water, the equipment MUST be flushed with fresh water before usage. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 74: Formula To Calculate The Expansion Vessel Pre-Pressure
Check that the total water volume in the installation is higher than the minimum water volume, the internal water volume of the outdoor unit NOT included: If… Then the minimum water volume is… Cooling operation 10 l Heating/defrost operation and… EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 75 Individual room thermostat (option) c Overpressure bypass valve (field supply) d Shut-off valve (delivered as accessory) M1...3 Individual motorised valve to control each loop (field supply) EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 76 The maximum water volume is 185 l in case the circuit is only filled with water, and 105 l in case the circuit is filled with water and glycol. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 77: Changing The Pre-Pressure Of The Expansion Vessel
Changing the pre-pressure of the expansion vessel should be done by releasing or increasing nitrogen pressure through the Schrader valve of the expansion vessel. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 78: To Check The Water Volume: Examples
Because 250 l is lower than 270 l, the expansion vessel is appropriate for the installation. 8.2 Connecting water piping 8.2.1 About connecting the water piping Before connecting the water piping Make sure the outdoor unit is mounted. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 79: Precautions When Connecting The Water Piping
When connecting the field piping, hold the nut on the inside of the unit in place using a spanner to provide extra leverage. 1 Connect the shut-off valve (with integrated filter) to the outdoor unit water inlet, using thread sealant. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 80: To Protect The Water Circuit Against Freezing
▪ Water pipe freeze prevention (see "Water pipe freeze prevention" [ 202]), EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 81 Types of glycol The types of glycol that can be used depend on whether the system contains a domestic hot water tank: EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 82 If glycol is present in the system, setting [E-0D] must be set to 1. If the glycol setting is NOT set correctly, the liquid inside the piping can freeze. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 83 Insulate the freeze protection valves in a similar way as the water piping, but do NOT insulate the inlet and outlet (release) of these valves. ▪ Do NOT make traps in the field piping. >10 cm >15 cm EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 84: To Fill The Water Circuit
Outside piping. Make sure the outside piping is insulated as instructed to protect against hazards. For piping in free air, it is recommended to use the insulation thickness as shown in below table as a minimum (with λ=0.039 W/mK). EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 85 Hydronic Piping Calculation tool. The Hydronic Piping Calculation tool is part of the Heating Solutions Navigator which can be reached via https://professional.standbyme.daikin.eu. Please contact your dealer if you have no access to Heating Solutions Navigator. This recommendation ensures good operation of the unit, however, local regulations may differ and shall be followed.
Page 86: Electrical Installation
Make electrical connections to the fixed wiring. ▪ All components procured on-site and all electrical construction MUST comply with the applicable legislation. WARNING ALWAYS use multicore cable for power supply cables. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 87: Guidelines When Connecting The Electrical Wiring
Round crimp-style terminal ▪ Use the following methods for installing wires: Wire type Installation method Single-core wire AA´ A´ a Curled single-core wire b Screw c Flat washer EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 88: About Electrical Compliance
▪ demand that the equipment ONLY consumes a limited amount of electricity during certain periods of time. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 89: Overview Of Electrical Connections Except External Actuators
With integrated backup heater With external backup heater kit 58 0 58 0 1 5 0 1 5 0 X5M/9+10 X5M/9+10 EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 90: Connections To The Outdoor Unit
Backup heater kit + Bypass "9.2.4 External backup heater kit" [ 100]. valve kit (in case of external backup heater kit) User interface "9.2.5 To connect the user interface" [ 107]. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 91 "9.2.13 To connect the safety thermostat (normally closed contact)" [ 116]. Smart Grid "9.2.14 To connect a Smart Grid" [ 117]. WLAN cartridge "9.2.15 To connect the WLAN cartridge (delivered as accessory)" [ 120] EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 92 Maximum running current: 100 mA For the main zone: ▪ [2.9] Control ▪ [2.A] Ext thermostat type For the additional zone: ▪ [3.A] Ext thermostat type ▪ [3.9] (read-only) Control EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 93 Remote indoor sensor See: ▪ Installation manual of the remote indoor sensor ▪ Addendum book for optional equipment Wires: 2×0.75 mm² [9.B.1]=2 (External sensor = Room) [1.7] Room sensor offset EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 94 Installation manual of the domestic hot heater (from mains to water tank outdoor unit) ▪ Addendum book for optional equipment Wires: 2+GND Maximum running current: 13 A [9.4] Booster heater EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 95: To Connect The Electrical Wiring To The Outdoor Unit
An excessive strip length may cause electrical shock or leakage 3 Insert the cables at the back of the unit, and route them through the unit to the appropriate terminal blocks. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 96: To Connect The Main Power Supply
L N N N PE N N N N N N N N N N N N N N N 1N~, 50 Hz, 220-240 V AC 180° EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 97 N N N N N N N N N N N N N N N 1N~, 50 Hz, 220-240 V AC 180° 3 If necessary, connect the separate normal kWh rate power supply. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 98 4 Connect the preferential power supply contact. X5M.10 X5M.9 180° 9 10 5 In case of a separate normal kWh rate power supply, disconnect X11Y from X11YA, and connect X11Y to X11YB. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 99: To Connect The Backup Heater Power Supply
"9.2.1 To connect the electrical wiring to the outdoor unit" [ 95]. 2 Connect the power supply cable (including earth) to the appropriate terminals as shown in the illustration below. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 100: External Backup Heater Kit
To connect the backup heater kit power supply ▪ To connect the backup heater kit to the outdoor unit Wires: See installation manual of the backup heater kit EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 101 >16 A and ≤75 A per phase). 1 Connect the backup heater power supply. A 4‑pole fuse is used for F1B. 2 If required, modify the connection on terminal X14M. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 102 1N~ 230 V 3N~ 400 V 3N~ 400 V K1M/1 K5M/13 52.9Ω 52.9Ω ∞ ∞ K1M/3 ∞ 105.8Ω 105.8Ω 105.8Ω K1M/5 ∞ 158.7Ω 105.8Ω 105.8Ω K1M/3 K1M/5 26.5Ω 52.9Ω 105.8Ω 105.8Ω EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 103 The distance between the high voltage and low voltage cables should be at least 50 mm. 1 On the backup heater kit, connect the LV and HV cables to the appropriate terminals as shown in the illustration below. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 104 180° 1 2 3 4 5 3 On the outdoor unit, connect the LV cable to the appropriate terminals as shown in the illustration below. X15M EKLBUHCB6W EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 105 Example: Given are an ambient temperature of 25°C and a relative humidity of 40%. If the leaving water evaporator temperature is <12°C, condensation will occur. Note: See the psychrometric chart for more information. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 106 0.1 m 5°C 0.5 m 0.2 m 2 On the outdoor unit, connect B to the appropriate terminals as shown in the illustration below. X2M.4 X2M.3 X2M.14a EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 107: To Connect The User Interface
2 Connect the user interface cable to the outdoor unit. Fix the cable with cable ties to the cable tie mountings. X5M.11 X5M.12 P1P2 X5M.16 X5M.15 a User interface: Required for operation. Delivered with the unit as accessory. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 108 ▪ Use the 2 screws and wall plugs. ▪ Use any of the 6 holes. The holes are compatible with standard electrical box extenders of 60 mm. 60 mm a Holes EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 109 Opening the user interface after it is installed If you need to open the user interface after it is installed, proceed as follows: 1 Remove the WLAN cartridge and USB memory stick (if any). EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 110: To Connect The Shut-Off Valve
95]. 2 Connect the valve control cable to the appropriate terminals as shown in the illustration below. NOTICE Only connect NO (normally open) valves. X2M.3 X2M.4 (NO) EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 111: To Connect The Electricity Meters
2 Connect the electricity meters cable to the appropriate terminals as shown in the illustration below. X5M.6 X5M.5 X5M.4 X5M.3 180° 3 4 5 6 3 Fix the cable with cable ties to the cable tie mountings. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 112: To Connect The Domestic Hot Water Pump
1 Access the electrical connections. See "9.2.1 To connect the electrical wiring to the outdoor unit" [ 95]. 2 Connect the alarm output cable to the appropriate terminals as shown in the illustration below. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 113: To Connect The Space Cooling/Heating On/Off Output
"9.2.1 To connect the electrical wiring to the outdoor unit" [ 95]. 2 Connect the space cooling/heating ON/OFF output cable to the appropriate terminals as shown in the illustration below. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 114: To Connect The Changeover To External Heat Source
Wires: 2×0.75 mm² Maximum load: 0.3 A, 250 V AC Minimum load: 20 mA, 5 V DC [9.C] Bivalent 1 Access the electrical connections. See "9.2.1 To connect the electrical wiring to the outdoor unit" [ 95]. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 115: To Connect The Power Consumption Digital Inputs
2 Connect the power consumption digital inputs cable to the appropriate terminals as shown in the illustration below. S6S (DI4) A8P.1 S7S (DI3) A8P.2 S8S (DI2) A8P.3 S9S (DI1) A8P.4 A8P.5 EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 116: To Connect The Safety Thermostat (Normally Closed Contact)
X5M.14 X5M.13 180° 1314 13 14 a Remove jumper 3 Fix the cable with cable ties to the cable tie mountings. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 117: To Connect A Smart Grid
Wires (low voltage Smart Grid contacts): 0.5 mm² [9.8.4]=3 (Benefit kWh power supply = Smart grid) [9.8.5] Smart grid operation mode [9.8.6] Allow electrical heaters [9.8.7] Enable room buffering [9.8.8] Limit setting kW EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 118 [9.8.7] Enable room buffering [9.8.8] Limit setting kW The wiring of the Smart Grid in case of high voltage contacts is as follows: X10M STEP 3 STEP 1 STEP 2 EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 119 Wires between the relays and X10M (AWG18 RED) 5 6 9 10 1 2 3 4 X10M 2 Connect the low voltage wiring as follows: X5M.4 X5M.3 S4S Smart Grid pulse meter (optional) EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 120: To Connect The Wlan Cartridge (Delivered As Accessory)
9.2.15 To connect the WLAN cartridge (delivered as accessory) [D] Wireless gateway 1 Insert the WLAN cartridge into the cartridge slot on the user interface of the indoor unit. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 121 Electrical installation EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 122: Finishing The Outdoor Unit Installation
2 Turn ON the power and leave it on for 6 hours. Result: The compressor will heat up and evaporate any refrigerant in the compressor. 3 Measure the insulation resistance again. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 123: Configuration
▪ The calculations of the software ▪ What you can see on and do with the user interface You can configure the system via the user interface. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 124: To Access The Most Used Commands
Move the cursor from left to right. ▪ Confirm the pin code and proceed. Installer pin code The Installer pin code is 5678. Additional menu items and installer settings are now available. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 125 3 Turn the left dial to select the first part of the setting and confirm by pressing the dial. 4 Turn the left dial to select the second part of the setting 01 15 EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 126: To Connect The Pc Cable To The Switch Box
1 Connect the USB connector of the cable to your PC. 2 Connect the plug of the cable to X10A on A1P (hydro PCB). X10A 3 Pay special attention to the position of the plug! EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 127: Configuration Wizard
(if applicable) Bivalent [9.C] Backup heater (if applicable) Voltage [9.3.2] "Backup heater" [ 194] Configuration [9.3.3] Capacity step 1 [9.3.4] Additional capacity step 2 [9.3.5] (if applicable) Main zone EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 128: Possible Screens
Comfort setpoint [5.2] Eco setpoint [5.3] Reheat setpoint [5.4] Hysteresis [5.9] and [5.A] 11.3 Possible screens 11.3.1 Possible screens: Overview The most common screens are as follows: EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 129: Home Screen
26 Feb 2020 22:19 Possible actions on this screen Go through the list of the main menu. Go to the main menu screen. Enable/disable breadcrumbs. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 130 Smart energy is currently being used for domestic hot water. Space operation mode Cooling Heating Outdoor / quiet mode Measured outdoor temperature Quiet mode active Outdoor unit Domestic hot water tank Standalone tank installed Water pressure EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 131 "15.4.1 To display the help text in case of a malfunction" [ 245] for more information. If the corresponding operation (for example: space heating) is not active, the circle is greyed out. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 132: Main Menu Screen
User settings mode and quiet mode. Displays data and information about the Information outdoor unit. Installer settings Restriction: Only for the installer. Gives access to advanced settings. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 133: Menu Screen
[1] Room temperature screen [2] Main zone screen °C °C – – Room Main zone [3] Additional zone screen [5] Tank temperature screen °C °C – – Tank Additional zone EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 134: Detailed Screen With Values
Selected setting and value Possible actions on this screen Go through the list of settings. Change the value. Go to the next setting. Confirm changes and proceed. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 135: Preset Values And Schedules
"Activation screen" in "Possible to a schedule. schedules" [ 136] Select which schedule you currently want to use for a specific control. The system contains some predefined schedules. You can: EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 136 This entry shows you where to activate it. ▪ Possible actions: Actions you can use when programming a schedule. For most schedules, you can program up to 6 actions per day. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 137 "To set the space operation mode" [ 169]. cooling > Operation mode schedule Schedule (per month) for when to operate the unit in heating mode and when in cooling mode. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 138 Possible actions: You can program 2 actions per > Booster heater > BSH day. allowance schedule ▪ Off: Booster heater operation NOT allowed. ▪ On: Booster heater operation allowed. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 139: Schedule Screen: Example
To clear the content of the week schedule 1 Select the name of the current schedule. User defined 1 2 Select Delete. Delete Rename Select 3 Select OK to confirm. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 140 In this example, Monday is the first day you programmed. Thus, the last programmed action is valid up to the first action of next Monday. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 141 5 Repeat this action for all other weekdays. — User defined 1 To program the schedule for Saturday and copy it to Sunday 1 Select Saturday. 2 Select Edit. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 142 INFORMATION Not all schedules can be renamed. Usage example: You work in a 3-shift system If you work in a 3-shift system, you can do the following: EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 143: Setting The Energy Prices
2 Program the selection using the scheduling screen. You can set — the High, Medium and Low electricity prices according to your electricity supplier. 3 Confirm the changes. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 144 Gas price=4.08+(5×0.9) Gas price=8.58 Calculation of the electricity price Electricity price=Actual electricity price+Incentive/kWh Electricity price=12.49+5 Electricity price=17.49 Price Value in breadcrumb Gas: 4.08 /kWh [7.6]=8.6 Electricity: 12.49 /kWh [7.5.1]=17 EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 145: Weather-Dependent Curve
See "11.5.4 Using weather-dependent curves" [ 148]. 11.5.2 2-points curve Define the weather-dependent curve with these two setpoints: ▪ Setpoint (X1, Y2) ▪ Setpoint (X2, Y1) EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 146: Slope-Offset Curve
Examples Weather-dependent curve when slope is selected: EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 147 The icon corresponds to the heat emitter for that zone: ▪ : Underfloor heating ▪ : Fan coil unit ▪ : Radiator ▪ : Domestic hot water tank EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 148: Using Weather-Dependent Curves
To change the weather-dependent curve Zone Go to … Main zone – Heating [2.5] Main zone > Heating WD curve Main zone – Cooling [2.6] Main zone > Cooling WD curve EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 149 ↑ — ↑ Cold Cold ↑ ↑ ↑ ↑ Cold ↓ ↑ ↓ ↑ — ↓ — ↓ Cold ↑ ↓ ↑ ↓ ↓ ↓ ↓ ↓ EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 150: Settings Menu
Schedule: ▪ No: Room temperature is directly controlled by the user. ▪ Yes: Room temperature is controlled by a schedule and can be modified by the user. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 151 Do NOT change the default room antifrost temperature [2-05]. ▪ Make sure that the water pipe freeze prevention is activated ([4-04]≠2). INFORMATION If a U4 error occurs, room frost protection is NOT guaranteed. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 152 ▪ Outdoor ambient temperature drops below 6°C ▪ the temperature setpoint of the leaving water will be lowered. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 153 When the dedicated Human Comfort Interface (BRC1HHDA used as room thermostat) is disconnected (because of incorrect wiring or damage of the cable), then room frost protection is NOT guaranteed. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 154 ▪ –5°C~5°C, step 0.5°C Room comfort setpoint Restriction: Only applicable if: ▪ Smart Grid is enabled ([9.8.4]=Smart grid), and ▪ Room buffering is enabled ([9.8.7]=Yes) EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 155: Main Zone
In Fixed LWT setpoint mode, the scheduled actions consist of desired leaving water temperatures, either preset or custom. ▪ In Weather dependent LWT setpoint mode, the scheduled actions consist of desired shift actions, either preset or custom. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 156 10°C. Heating WD curve Set weather-dependent heating for the main zone (if [2.4]=1 or 2): EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 157 Note: This value should be lower than [1‑02] as for high outdoor temperatures less warm water is required. Cooling WD curve Set weather-dependent cooling for the main zone (if [2.4]=2): EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 158 It is important to set Emitter type correctly and in accordance with your system layout. The target delta T for the main zone depends on it. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 159 Example underfloor heating: 40–5/2=37.5°C To compensate, you can: ▪ Increase the weather-dependent curve desired temperatures [2.5]. ▪ Enable leaving water temperature modulation and increase the maximum modulation [2.C]. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 160 [9-00] Heating maximum: ▪ [2‑0C]=2 (emitter type main zone = radiator) 37°C~60°C ▪ Else: 37°C~55°C [2.8.3] [9-03] Cooling minimum: ▪ 5°C~18°C [2.8.4] [9-02] Cooling maximum: ▪ 18°C~22°C EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 161 (EKRTRB). Leaving water temperature: Delta T In heating for the main zone, the target delta T (temperature difference) depends on the selected emitter type for the main zone. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 162 Additionally, also the desired leaving water temperature must be configured: if Modulation is enabled, the unit automatically calculates the desired leaving water temperature. These calculations are based on: EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 163 WD curve type The weather-dependent curve can be defined using the 2-points method or the Slope-Offset method. "11.5.2 2-points curve" [ 145] and "11.5.3 Slope-offset curve" [ 146]. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 164: Additional Zone
Define a heating temperature schedule for the additional zone via [3.2] Heating schedule. "11.4.3 Schedule screen: Example" [ 139]. Cooling schedule Define a cooling temperature schedule for the additional zone via [3.3] Cooling schedule. "11.4.3 Schedule screen: Example" [ 139]. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 165 [9‑05]~min(45, [9‑06])°C Note: This value should be lower than [0‑01] as for high outdoor temperatures less warm water is required. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 166 ▪ 2: Radiator The setting of the emitter type has an influence on the space heating setpoint range and the target delta T in heating as follows: EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 167 External room thermostat if the control type of the main zone is: External room thermostat,or Room thermostat. Ext thermostat type Only applicable in external room thermostat control. Also see "11.6.3 Main zone" [ 155]. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 168: Space Heating/Cooling
[2.E] / [3.C] ▪ 2-points ▪ Slope-Offset 11.6.5 Space heating/cooling INFORMATION Cooling is only applicable in case of reversible models. Overview The following items are listed in the submenu: EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 169 While the unit is in operation, the status indicator will light up blue constantly. To set the space operation mode 1 Go to [4.1]: Space heating/cooling > Operation mode EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 170 If the outdoor temperature is between the Space heating off temperature and the Space cooling off temperature, the operation mode remains unchanged. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 171 Changeover settings related to the indoor temperature. Only applicable when Automatic is selected and the system is configured in room thermostat control with 1 leaving water temperature zone and quick heat emitters. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 172 LWT zone. Code Description [4.4] [7‑02] ▪ 0: Single zone Only one leaving water temperature zone: a Main LWT zone EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 173 Pump operation mode When the space heating/cooling operation is OFF, the pump is always OFF. When space heating/cooling operation is ON, you have the choice between these operation modes: EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 174 Sample is ONLY available in leaving water temperature control. a Space heating/cooling control b Off c On d LWT temperature e Actual f Desired g Pump operation EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 175 T control and comfort are NOT guaranteed. ▪ 1: 90% pump speed ▪ 2: 80% pump speed ▪ 3: 70% pump speed ▪ 4: 60% pump speed EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 176 (l/min) b (l/min) [9-0D]=2/6 [9-0D]=3/7 a (kPa) a (kPa) b (l/min) b (l/min) [9-0D]=4/8 a (kPa) b (l/min) a External static pressure b Water flow rate EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 177 Code Description [4.B] [9-04] Overshoot: ▪ 1°C~4°C Undershoot Restriction: This function is only applicable in cooling mode during compressor startup. It is NOT applicable for stable operation. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 178: Tank
To activate powerful operation Activate or deactivate Powerful operation as follows: 1 Go to [5.1]: Tank > Powerful operation 2 Turn powerful operation Off or On. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 179 When the tank temperature rises above this value, domestic hot water preparation and space heating/cooling are executed sequentially. Code Description [5.4] [6-0C] Reheat setpoint: ▪ 30°C~min(50,[6‑0E])°C EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 180 CAUTION The disinfection function settings MUST be configured by the installer according to the applicable legislation. Code Description [5.7.1] [2‑01] Activation: ▪ 0: No ▪ 1: Yes EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 181 This maximum allowable hot water temperature shall be selected according to the applicable legislation. CAUTION Make sure that the disinfection function start time [5.7.3] with defined duration [5.7.5] is NOT interrupted by possible domestic hot water demand. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 182 You can use this setting to limit the temperature at the hot water taps. The maximum temperature is NOT applicable during disinfection function. See disinfection function. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 183 (according to the weather-dependent curve). During weather-dependent operation, the end-user cannot adjust the desired tank temperature on the user interface. Also see "11.5 Weather-dependent curve" [ 145]. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 184 Code Description [5.D] [6-01] The temperature difference determining the heat pump OFF temperature. Range: 0°C~10°C Example: setpoint (T )>maximum heat pump temperature–[6‑01] (T –[6‑01]) HP MAX EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 185 In [2.E] WD curve type, you can choose which method you want to use. In [5.E] WD curve type, the chosen method is shown read-only (same value as in [2.E]). EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 186: User Settings
Setting the starting date and ending date of your holiday. To check if holiday mode is activated and/or running is displayed on the home screen, holiday mode is active. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 187 To use quiet mode 1 Go to [7.4.1]: User settings > Quiet > Mode. 2 Do one of the following: — EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 188 Price value ranging from 0.00~990 valuta/kWh (with 2 significant values). To set the electricity price 1 Go to [7.5.1]/[7.5.2]/[7.5.3]: User settings > Electricity price > High/Medium/Low. 2 Select the correct electricity price. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 189 188]. Example This is an example and the prices and/or values used in this example are NOT accurate. Data Price/kWh Gas price 4.08 Electricity price 12.49 EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 190: Information
Reset the configuration settings stored in the MMI (user interface delivered as accessory). Example: Energy meterings, holiday settings. INFORMATION This does not reset the configuration settings and field settings of the hydro module of the outdoor unit. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 191: Installer Settings
WLAN. [8.9] Running hours Running hours of specific system components 11.6.9 Installer settings Overview The following items are listed in the submenu: EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 192 The following setting determines if the system can prepare domestic hot water or not, and which tank is used. Set this setting according to the actual installation. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 193 In case of a third-party tank, we recommend to use the following settings: Code Item Third-party tank Coil≥1.05 m² Coil≥1.8 m² [9.2.1] [E‑07] Tank type 7: 3rd party, 8: 3rd party, small coil big coil [4-05] Thermistor type 0: Automatic EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 194 To save energy, only turn on the pump during periods of the day when instant hot water is necessary. Backup heater Besides the type of backup heater, the voltage, configuration and capacity must be set on the user interface. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 195 [6‑03]+[6‑04]. INFORMATION If [4‑0A]=3 and emergency mode is active, the power usage of the backup heater is maximal and equal to 2×[6‑03]+[6‑04]. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 196 When heating of the DHW by the heat pump is too slow, it may affect a comfortable operation of the space heating/cooling circuit. If so, allow the backup heater to assist during DHW operation by setting [4-00]=1 or 2. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 197 ▪ Make sure that [8‑03] is always in relation with the maximum running time [8‑01]. Range: 20~95 minutes EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 198 NOT active in domestic hot water operation. Same as setting 1, but simultaneous heat pump domestic hot water operation and booster heater operation is not allowed. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 199 Description [9.5.1] [4-06] ▪ 0: Manual ▪ 1: Automatic ▪ 2: auto SH reduced/DHW on ▪ 3: auto SH reduced/DHW off ▪ 4: auto SH normal/DHW off EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 200 If you add glycol to the water, you also need to install a flow switch (EKFLSW2). Balancing Priorities For systems with a separate domestic hot water tank. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 201 1 Heat pump domestic water heating mode (1=active, 0=not active) 2 Hot water request for heat pump (1=request, 0=no request) t Time [8-04]: Additional timer at [4-02]/[F-01] EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 202 [4-02] or [F-01]. Range: 0~95 minutes Water pipe freeze prevention Only relevant for installations with water piping outdoors. This function tries to protect outdoor water piping from freezing. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 203 [9.8.3] [D-05] Restriction: Only applicable if [9.8.4] is NOT set to Smart grid. Allow pump: ▪ 0 No: Pump is forced off ▪ 1 Yes: No limitation EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 204 See also below table (Smart Grid operation modes). [9.8.6] Restriction: Only applicable if [9.8.4]=Smart grid. To set if electrical heaters are allowed. Allow electrical heaters: ▪ ▪ EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 205 The 2 incoming Smart Grid contacts (see "9.2.14 To connect a Smart Grid" [ 117]) can activate the following Smart Grid modes: Smart Grid contact [9.8.5] Smart grid operation mode Free running Forced off EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 206 NOT possible in Forced on and Recommended on operation modes. Power consumption control Power consumption control "6 Application guidelines" [ 26] for detailed information about this functionality. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 207 Limits when [9.9.1]=Inputs and [9.9.2]=kW: Code Description [9.9.9] [5-09] Limit 1: 0 kW~20 kW [9.9.A] [5-0A] Limit 2: 0 kW~20 kW [9.9.B] [5-0B] Limit 3: 0 kW~20 kW [9.9.C] [5-0C] Limit 4: 0 kW~20 kW EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 208 (BBR16 activation and BBR16 power limit). After 2 weeks, the unit freezes these settings. Note: This is different from the permanent power limitation, which is always changeable. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 209 4 100/kWh: Installed ▪ 5 1000/kWh: Installed In case of pulse meter for photovoltaic panels: ▪ 6 100/kWh for PV panel: Installed ▪ 7 1000/kWh for PV panel: Installed EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 210 The outdoor temperature is averaged over the selected time period. Code Description [9.B.3] [1-0A] Averaging time: ▪ 0: No averaging ▪ 1: 12 hours ▪ 2: 24 hours ▪ 3: 48 hours ▪ 4: 72 hours EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 211 The switch-over between the heat pump system and the auxiliary boiler is based on the following settings: ▪ [C‑03] and [C‑04] ▪ Electricity price: [7.5.1], [7.5.2], [7.5.3] ▪ Gas price: [7.6] [C‑03], [C‑04], and T calc EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 212 COP = (Electricity price / gas price) × boiler efficiency ▪ Electricity price: 20 c€/kWh ▪ Gas price: 6 c€/kWh ▪ Boiler efficiency: 0.9 Then: COP = (20/6)×0.9 = 3 EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 213 Depending on the used boiler, this should be chosen as follows: Code Description [9.C.2] [7‑05] ▪ 0: Very high ▪ 1: High ▪ 2: Medium ▪ 3: Low ▪ 4: Very low EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 214 To enable the power saving function setting, [E‑08] needs to be enabled on the user interface. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 215 Export the configuration settings of the unit to a USB memory stick, via the MMI (the user interface delivered as accessory). When troubleshooting, these settings can be provided to our Service department. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 216 0 No : The system only has a main zone. ▪ 1 N/A ▪ 2 Yes: A bizone kit is installed in order to add an additional temperature zone. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 217 The speed of the main zone pump can be fixed with this setting. Code Description [9.P.4] [7-0B] Main zone pump fixed PWM: Fixed pump speed for main (mixed) zone. ▪ 20~95% (default: 95) EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 218: Commissioning
[C.2] Space heating/cooling Operation [C.3] Tank Malfunctioning Room To enable or disable functionalities In the operation menu, you can separately enable or disable functionalities of the unit. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 219: Wlan
This needs the following components: WLAN cartridge The WLAN cartridge needs to be inserted in the user interface. See the installation manual of the WLAN cartridge. Router Field supply. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 220 Code Description [D.5] Home network connection: ▪ Disconnected from [WLAN_SSID] ▪ Connected to [WLAN_SSID] Cloud connection: Read out the status of the connection to the cloud. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 221 Configuration Code Description [D.6] Cloud connection: ▪ Not connected ▪ Connected EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 222: Menu Structure: Overview User Settings
(**) Only accessible by installer (***) Only applicable when WLAN is installed INFORMATION Depending on the selected installer settings and unit type, settings will be visible/ invisible. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 223: Menu Structure: Overview Installer Settings
[9.C] Bivalent Bivalent Boiler efficiency Temperature Hysteresis (*) Only applicable in Swedish language. INFORMATION Depending on the selected installer settings and unit type, settings will be visible/ invisible. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 224: Commissioning
12 Commissioning NOTICE General commissioning checklist. Next to the commissioning instructions in this chapter, a general commissioning checklist is also available on the Daikin Business Portal (authentication required). The general commissioning checklist is complementary to the instructions in this chapter and can be used as a guideline and reporting template during the commissioning and hand-over to the user.
Page 225: Precautions When Commissioning
There are NO loose connections or damaged electrical components in the switch box. There are NO damaged components or squeezed pipes on the inside of the outdoor unit. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 226: Checklist During Commissioning
1 Check the hydraulic configuration to find out which space — heating loops can be closed by mechanical, electronic, or other valves. 2 Close all space heating loops that can be closed. — EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 227: Air Purge Function
– manually switch the position of the valve kit's 3‑way valve by turning its knob, this to prevent air from remaining in the bypass. For more information, see "9.2.4 External backup heater kit" [ 100]. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 228 3 In the menu, set Type = Automatic. 4 Select Start air purge. 5 Select OK to confirm. Result: The air purge starts. It stops automatically when done. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 229: Operation Test Run
Perform an actuator test run to confirm the operation of the different actuators. For example, when you select Pump, a test run of the pump will start. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 230: Underfloor Heating Screed Dryout
▪ checking the proper functioning of the setup on a regular basis, ▪ performing the correct program complying with the type of the used screed. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 231 The underfloor heating screed dryout function is active even if the user does NOT confirm emergency operation. ▪ During underfloor heating screed dryout, pump speed limitation [9‑0D] is NOT applicable. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 232 2 Press the left dial to open the menu structure and to: 1 View the status of sensors and actuators. — 2 Adjust the current program — EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 233 — If the UFH screed dryout program was stopped due to a power failure and the power resumes, the program will automatically restart the last implemented step. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 234: Hand-Over To The User
▪ Show the user what to do for the maintenance of the unit. ▪ Explain the user about energy saving tips as described in the operation manual. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 235: Maintenance And Service
General maintenance/inspection checklist. Next to the maintenance instructions in this chapter, a general maintenance/inspection checklist is also available on the Daikin Business Portal (authentication required). The general maintenance/inspection checklist is complementary to the instructions in this chapter and can be used as a guideline and reporting template during maintenance.
Page 236: Yearly Maintenance Outdoor Unit: Instructions
Flush and clean the complete tank, including the piping between the relief valve and cold water inlet. To make sure this water originates from the tank, check after a tank heat up cycle. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 237 OFF. WARNING If the internal wiring is damaged, it has to be replaced by the manufacturer, its service agent or similarly qualified persons. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 238: Troubleshooting
MUST NOT be supplied through an external switching device, such as a timer, or connected to a circuit that is regularly turned ON and OFF by the utility. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 239: Solving Problems Based On Symptoms
15.3.2 Symptom: Hot water does NOT reach the desired temperature Possible causes Corrective action One of the tank temperature sensors is See the service manual of the unit for broken. the corresponding corrective action. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 240: Symptom: The Compressor Does Not Start (Space Heating Or Domestic Water Heating)
Domestic hot water (including Change the schedule to not start both disinfection) and space heating operation modes at the same moment. operation are scheduled to start at the same time. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 241: Symptom: The System Is Making Gurgling Noises After Commissioning
(0.5 cm). Then turn the deblocking screw back and forth until the rotor is deblocked. Note: Do NOT use excessive force. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 242: Symptom: The Pump Is Making Noise (Cavitation)
0 m. The maximum water circuit head is 5 m. Check the installation requirements. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 243: Symptom: The Water Pressure Relief Valve Leaks
> Backup heater > Equilibrium temperature [5‑01] There is air in the system. Purge air manually or automatically. See the air purge function in the chapter "12 Commissioning" [ 224]. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 244: Symptom: The Pressure At The Tapping Point Is Temporarily Unusually High
The disinfection operation was stopped Do NOT stop tank operation during manually: [C.3] Operation > Tank was disinfection. turned off during disinfection. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 245: Solving Problems Based On Error Codes
Water flow problem. Pump deblocking active 7H-08 Pump abnormality during operation (pump feedback) 80-00 Returning water temperature sensor problem 81-00 Leaving water temperature sensor problem 81-01 Mixed water thermistor abnormality. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 246 Leakage current detection error E3-00 OU: Actuation of high pressure switch (HPS) E3-24 High pressure sensor abnormality E4-00 Abnormal suction pressure E5-00 OU: Overheat of inverter compressor motor EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 247 OU: Electrical box temperature rise problem L4-00 OU: Malfunction of inverter radiating fin temperature rise L5-00 OU: Inverter instantaneous overcurrent (DC) L8-00 Malfunction triggered by a thermal protection in the inverter PCB EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 248 U8-11 Connection with the Wireless gateway lost UA-00 Indoor unit, outdoor unit matching problem UA-17 Tank type problem UF-00 Reversed piping or bad communication wiring detection. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 249 Powerful operation takes a very long time to heat up and the error code AJ-03 is displayed. ▪ During anti-legionella operation (weekly), the error code AH-00 is displayed because the unit cannot reach the requested temperature required for tank disinfection. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 250 A malfunctioning booster heater will have an impact on energy metering and power consumption control. INFORMATION The user interface will display how to reset an error code. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 251: Disposal
If the compressor is still running and the stop valve is open during pump down, air will be sucked into the system. Compressor breakdown or damage to the system can result due to abnormal pressure in the refrigerant cycle. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 252 6 After 2-3 minutes, close the gas stop valve and stop the pump down operation. a Liquid stop valve b Closing direction c Hexagonal wrench d Valve lid e Gas stop valve EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 253: Technical Data
Technical data 17 Technical data A subset of the latest technical data is available on the regional Daikin website (publicly accessible). The full set of latest technical data is available on the Daikin Business Portal (authentication required). In this chapter 17.1...
Page 254: Piping Diagram: Outdoor Unit
Heat exchanger Screw connection q 4‑way valve Flare connection r Accumulator Quick coupling s Compressor Brazed connection t Muffler u Gas stop valve with service port EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 255 Heat exchanger Connections: p 4‑way valve Screw connection q Accumulator Flare connection r Compressor Quick coupling s Muffler Brazed connection t Gas stop valve with service port EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 256: Wiring Diagram: Outdoor Unit
Connector Connector Connector Fuse T 6.3 A 250 V FU1, FU2 Fuse T 3.15 A 250 V Fuse T 30 A 250 V Connector IPM* Intelligent power module Connector LED A Pilot lamp Reactor Compressor motor EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 257 Noise filter (ferrite core) Noise filter NOTES: When operating, do not short-circuit protection device(s) S1PH and Q1L. Colours: BLK: black; RED: red; BLU: blue; WHT: white; GRN: green; YLW: yellow EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 258 External backup heater terminal Booster heater power supply terminal Field wiring terminal for DC Internal backup heater power supply terminal X10M Smart Grid terminal Earth wiring Field supply EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 259 * Valve kit PC (A15P) * Power circuit PHC1 (A4P) * Optocoupler input circuit * Thermal protector booster heater # Safety thermostat Q*DI # Earth leakage circuit breaker EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 260 DC / 12 mA detection (voltage supplied 12 V DC / 12 mA detection (voltage by PCB) supplied by PCB) Options: ext. heat source output, alarm Options: external heat source output, output alarm output EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 261 Additional leaving water temperature zone Main LWT zone Main leaving water temperature zone Only for ext. sensor (floor or ambient) Only for external sensor (floor or ambient) EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 262 *: Optional; #: Field supply Main PCB * Digital I/O PCB * Demand PCB # Overcurrent fuse backup heater K1A, K2A * High voltage Smart Grid relay Safety contactor backup heater EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 263 * Terminal strip (booster heater power supply) # Terminal strip (power supply at client side) Terminal strip (integrated backup heater power supply) X10M * Terminal (high voltage Smart Grid) Connector Terminal strip EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 264 A8P: X801M: 3-5 4 core Optional part for EWA*/EWYA* signal X5M: 15-16 A11P: X1B: 1-2 2 core Power limitation demand input 4 A8P: X801M: 4-5 signal 4D139354 A EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 265: Esp Curve: Outdoor Unit
Selecting a flow outside the operating area can damage the unit or cause the unit to malfunction. See also the minimum and maximum allowed water flow range in the technical specification. ▪ Water quality must be according to EU directive 2020/2184. EBLA04~08E2V3+E23V3 + EDLA04~08E2V3+E23V3 Installer reference guide Daikin Altherma 3 M 4P685228-1A – 2022.05...
Page 266: Glossary
Optional equipment Equipment made or approved by Daikin that can be combined with the product according to the instructions in the accompanying documentation. Field supply Equipment NOT made by Daikin that can be combined with the product according to the instructions in the accompanying documentation.
Page 267: Field Settings Table
1/14 Field settings table Applicable indoor units EBLA04E23V3 EDLA04E23V3 EBLA06E23V3 EDLA06E23V3 EBLA08E23V3 EDLA08E23V3 EBLA04E2V3 EDLA04E2V3 EBLA06E2V3 EDLA06E2V3 EBLA08E2V3 EDLA08E2V3 Notes (*1) EBLA* (*2) EDLA* (*3) *23V3 (*4) *2V3 4P685235-1 - 2022.03...
Page 268 2/14 Installer setting at variance with Field settings table default value Breadcrumb Setting name Range, step Date Value Default value Room └─ Antifrost 1.4.1 [2-06] Activation 0: No 1: Yes 1.4.2 [2-05] Room setpoint 4~16°C, step: 1°C 12°C └─ Setpoint range 1.5.1 [3-07] Heating minimum...
Page 269 3/14 Installer setting at variance with Field settings table default value Breadcrumb Setting name Range, step Date Value Default value └─ Modulation 2.C.1 [8-05] Modulation 0: No 1: Yes 2.C.2 [8-06] Max modulation 0~10°C, step: 1°C 5°C Main zone WD curve type 0: 2-points 1: Slope-Offset Additional zone...
Page 270 4/14 Installer setting at variance with Field settings table default value Breadcrumb Setting name Range, step Date Value Default value [9-0D] Pump speed limitation 0~8, step:1 0 : No limitation 1~4 : 90~60% pump speed 5~8 : 90~60% pump speed during sampling 6 80% pump speed Space heating / cooling...
Page 271 5/14 Installer setting at variance with Field settings table default value Breadcrumb Setting name Range, step Date Value Default value Installer settings └─ Configuration wizard └─ System 9.1.3.2 [E-03] BUH type R/O (*3) 0: No heater (*4) R/W (*4) 1: External heater 2: 3V (*3) 9.1.3.3 [E-05]...
Page 272 6/14 Installer setting at variance with Field settings table default value Breadcrumb Setting name Range, step Date Value Default value 9.1.8.1 [2-0D] Emitter type 0: Underfloor heating 1: Fancoil unit 2: Radiator 9.1.8.3 Setpoint mode 0: Fixed 1: WD heating, fixed cooling 2: Weather dependent 9.1.8.4 Schedule...
Page 273 7/14 Installer setting at variance with Field settings table default value Breadcrumb Setting name Range, step Date Value Default value └─ Booster heater 9.4.1 [6-02] Capacity 0~10kW, step: 0,2kW 9.4.3 [8-03] BSH eco timer 20~95 min, step: 5 min 50 min 9.4.4 [4-03] Operation...
Page 274 8/14 Installer setting at variance with Field settings table default value Breadcrumb Setting name Range, step Date Value Default value 9.A.2 [D-09] Electricity meter 2 / PV meter 0: No 1: 0,1 pulse/kWh 2: 1 pulse/kWh 3: 10 pulse/kWh 4: 100 pulse/kWh 5: 1000 pulse/kWh 6: 100 pulse/kWh (PV meter) 7: 1000 pulse/kWh (PV meter)
Page 275 9/14 Installer setting at variance with Field settings table default value Breadcrumb Setting name Range, step Date Value Default value [1-03] Leaving water value for high ambient temp. for LWT main zone [9-01]~min(45, [9-00])°C , step: 1°C heating WD curve. [2-0C]=0 25°C [2-0C]=1...
Page 276 10/14 Installer setting at variance with Field settings table default value Breadcrumb Setting name Range, step Date Value Default value [3-0A] What is the pump model 0: pump model 0 1: pump model 1 [4-00] What is the BUH operation mode? 0: Restricted 1: Allowed 2: Only DHW...
Page 277 11/14 Installer setting at variance with Field settings table default value Breadcrumb Setting name Range, step Date Value Default value [6-0E] What is the maximum temperature setpoint? E-07 = 0 40~ 60°C, step: 1°C 60°C E-07 = 3 40~ 75°C, step: 1°C 75°C E-07 = 5 40~ 80°C, step: 1°C...
Page 278 12/14 Installer setting at variance with Field settings table default value Breadcrumb Setting name Range, step Date Value Default value [9-0C] Room temperature hysteresis. 1~6°C, step: 0,5°C 1 °C [9-0D] Pump speed limitation 0~8, step:1 0 : No limitation 1~4 : 90~60% pump speed 5~8 : 90~60% pump speed during sampling 6 80% pump speed...
Page 279 13/14 Installer setting at variance with Field settings table default value Breadcrumb Setting name Range, step Date Value Default value [E-07] What kind of DHW tank is installed? 0 OSO tank 150/180 1 FS with BUH 2 FS with BSH 3 OSO tank 200/250/300 4 Rotex without BSH (HYB) 5 Rotex with BSH...
Page 280 14/14...
Page 284 4P685228-1A 2022.05 Verantwortung für Energie und Umwelt...

This manual is also suitable for:

Altherma 3 m Ebla06e2v3 Ebla08e2v3 Ebla04e23v3 Ebla06e23v3 Ebla08e23v3 ... Show all

Daikin EBLA04E2V3 Installer's Reference Manual

Quick Links

Related Manuals for Daikin EBLA04E2V3

Summary of Contents for Daikin EBLA04E2V3

This manual is also suitable for:

Table of Contents
