Daikin altherma 3 M Service Manual page 293

c
a
a Liquid service port
b Gas service port
c Flexible hose
d Manifold
e Recovery unit
f Vacuum pump
g Scale
h Recovery cylinder
i Vacuum setup
j Internal service port
EBLA09~16DA + EDLA09~16DA
Daikin Altherma 3 M
ESIE20-06A – 2021.03
Service tool
2 Setup a vacuum line between recovery unit discharge and the recovery bottle.
Without this additional setup, the discharge line from the recovery device to
the refrigerant cylinder would not have been vacuumed.
3 Connect the vacuum pump, manifold, recovery unit, and refrigerant recovery
cylinder to the service ports of the refrigerant circuit as shown below. Make
sure the stop valves are open.
j
c c
b
4
|
Recovery cylinder
Vacuum pump
e
Third party components
Remark
Compatible with the
refrigerant to be
recovered
2-stage, equipped with
solenoid valve
f g h
Service manual
d
i
293
