Displaying integrated measured values

The instrument can simultaneously integrates the current (I) and active power (P), and displays
positive, negative, and total values.
Displaying integration information
Display screen [MEAS]
When the integration control is set to
the [Integration Time]
start time, integration stop time, and elapsed time
common to all wiring configurations.
When the integration control is set to
it displays the integration start time, integration stop
time, and elapsed time of the wiring configuration
selected using the
CH
• The parameters that can be integrated vary with the wiring mode and the integration mode.
See "2.5 Setting Wiring Mode and Configuring Current Sensor Settings" (p. 41) and "Integration
mode" (p. 69).
• This information can also be selected and displayed on the
See "3.1 Displaying Measured Values" (p. 51).
> [VALUE] > [BASIC]
1 1
[All Channel],
field displays the integration
[Each Wiring],
keys.
HIOKI PW8001A961-00
Integrating Current and Power
1
Tap [Integ.].
2
Switch the displayed channel using the
keys for channel selection.
CH
The displayed channel will change each time
the keys are pressed.
CH
Integrated positive current value of
Ch. 1
Ih1+
(displayed only when the integration
mode is DC)
Integrated negative current value of
Ch. 1
Ih1−
(displayed only when the integration
mode is DC)
Sum of integrated current values of
Ih1
Ch. 1
Integrated positive active power
WP1+
value of Ch. 1
Integrated negative active power
WP1−
value of Ch. 1
Sum of integrated active power
WP1
values of Ch. 1
CUSTOM screen.
