Motor Measurement (Motor Analysis-Equipped Model)

Configuring the motor input settings

Connect torque sensors and tachometers by referring to "Motor measurement wiring" (p. 78).
Configure the motor analysis settings based on those connections.
Display screen [INPUT]
1 1
2 2
Upper frequency limit
This setting specifies the lowest frequency that exceeds the maximum frequency of the input pulse signal.
When [Motor analysis option wiring]
D/A output.
When using motor analysis mode, this setting is used as the pulse frequency that is used to display RPMs and
motor powers and as a pulse frequency to calculate the upper limit value for the D/A output.
(RPM upper limit value) =
(Motor power upper limit value) = (Maximum torque value)
If the input RMS signal setting is [Analog], the RMS upper limit is calculated by multiplying the scaled RMS
value by the voltage range value.
Lower frequency limit
This setting specifies the lower frequency limit for measurement of the input pulse signal.
When the following synchronization sources are selected, the lower limit frequency is also used as the lower
frequency limit for measurement.
Ext1, Ext2, Ext3, Ext4
Zph1, Zph3
Ch. B, Ch. D, Ch. F, Ch. H
84
> [MOTOR]
3 3
4 4
5 5
6 6
is set to [Individual
×
60 (Set upper frequency limit)
(Pulse count setting)
HIOKI PW8001A961-00
1
Tap [Motor analysis option wiring]
select.
2
Tap [CH A-D] or [CH E-H]
channels you wish to change the
settings.
3
Tap the [Upper f lim.]
box, and select the frequency from the
list.
Set this when pulses are to be input for the
motor input.
100 Hz, 500 Hz, 1 kHz, 5 kHz,
Upper f lim.
10 kHz, 50 kHz, 100 kHz,
500 kHz, 1 MHz, 2 MHz
Lower f lim. 0.1 Hz, 1 Hz, 10 Hz, 100 Hz
Input], the setting is used as the upper limit for
× ×
2 (RPM upper limit value)
π
×
60
to
to display
and [Lower f lim.]
