7.8 Measured Value Save Data Format

Header structure

The following header information (which consists of parameter names saved in the first line of the
file) is used when measured data is automatically or manually saved in a file.
• The selected parameters are outputted beginning from top to bottom and from left to right of the
table.
• Measured data is outputted starting from the first line immediately below the header in the header
order.
• The first four parameters (Date, Time, Status, and Status 1 to Status 8) and the harmonic status
(HARM Status) are always outputted regardless of whether they have been selected.
• The instrument outputs the Status 1 to Status 8 information of installed input modules.
• If the motor analysis option is installed, the status (Status M) of the motor channel is outputted.
Instrument
Output items
Year, month, day
Time
Time (ms)
Elapsed time
Elapsed time (ms)
Status
Channel status
Motor status
Basic measurement items
(The string Slv is added to each header of the basic measurement items for the subordinate units when it is operating in numerical
synchronization mode.)
The basic measurement items for subordinate units are outputted after the basic measurement items for the master unit is
outputted.
Voltage RMS value
RMS equivalent of average
rectified voltage value
Voltage AC component
Voltage simple average
Voltage fundamental wave
component
Voltage waveform peak (+)
Voltage waveform peak (−)
Total harmonic voltage
distortion
Voltage ripple factor
Voltage unbalance rate
symbol
Date
Time
Time (ms)
(Outputted only when the interval setting is less than 1 s)
Etime
Etime (ms)
(Outputted only when the interval setting is less than 1 s)
Status
Status1, Status2, Status3, Status4, Status5, Status6, Status7, Status8
StatusM
Urms1, Urms2, Urms3, Urms4, Urms5, Urms6, Urms7, Urms8
Urms Urms12, Urms23, Urms34, Urms45, Urms56, Urms67, Urms78
Urms123, Urms234, Urms345, Urms456, Urms567, Urms678
Umn1, Umn2, Umn3, Umn4, Umn5, Umn6, Umn7, Umn8
Umn Umn12, Umn23, Umn34, Umn45, Umn56, Umn67, Umn78
Umn123, Umn234, Umn345, Umn456, Umn567, Umn678
Uac Uac1, Uac2, Uac3, Uac4, Uac5, Uac6, Uac7, Uac8
Udc Udc1, Udc2, Udc3, Udc4, Udc5, Udc6, Udc7, Udc8
Ufnd Ufnd1, Ufnd2, Ufnd3, Ufnd4, Ufnd5, Ufnd6, Ufnd7, Ufnd8
Upk+ PUpk1, PUpk2, PUpk3, PUpk4, PUpk5, PUpk6, PUpk7, PUpk8
Upk− MUpk1, MUpk2, MUpk3, MUpk4, MUpk5, MUpk6, MUpk7, MUpk8
Uthd Uthd1, Uthd2, Uthd3, Uthd4, Uthd5, Uthd6, Uthd7, Uthd8
Urf Urf1, Urf2, Urf3, Urf4, Urf5, Urf6, Urf7, Urf8
Uunb Uunb123, Uunb234, Uunb345, Uunb456, Uunb567, Uunb678
HIOKI PW8001A961-00
Measured Value Save Data Format
Header and order
137
