Measured Value Save Data Format
Output items
Current RMS value
RMS equivalent of average
rectified voltage value
Current AC component
Current simple average
Current fundamental wave
component
Current waveform peak (+)
Current waveform peak (−)
Total harmonic current
distortion
Current ripple factor
Current unbalance rate
Active power
Fundamental wave active
power
Apparent power
Fundamental wave
apparent power
Reactive power
Fundamental wave reactive
power
Power factor
Fundamental wave power
factor
Voltage phase angle
Current phase angle
Power phase angle
Voltage frequency
Current frequency
Integrated positive current
value
Integrated negative current
value
138
Instrument
symbol
Irms1, Irms2, Irms3, Irms4, Irms5, Irms6, Irms7, Irms8
Irms Irms12, Irms23, Irms34, Irms45, Irms56, Irms67, Irms78
Irms123, Irms234, Irms345, Irms456, Irms567, Irms678
Imn1, Imn2, Imn3, Imn4, Imn5, Imn6, Imn7, Imn8
Imn Imn12, Imn23, Imn34, Imn45, Imn56, Imn67, Imn78
Imn123, Imn234, Imn345, Imn456, Imn567, Imn678
Iac Iac1, Iac2, Iac3, Iac4, Iac5, Iac6, Iac7, Iac8
Idc Idc1, Idc2, Idc3, Idc4, Idc5, Idc6, Idc7, Idc8
Ifnd Ifnd1, Ifnd2, Ifnd3, Ifnd4, Ifnd5, Ifnd6, Ifnd7, Ifnd8
Ipk+ PIpk1, PIpk2, PIpk3, PIpk4, PIpk5, PIpk6, PIpk7, PIpk8
Ipk− MIpk1, MIpk2, MIpk3, MIpk4, MIpk5, MIpk6, MIpk7, MIpk8
Ithd Ithd1, Ithd2, Ithd3, Ithd4, Ithd5, Ithd6, Ithd7, Ithd8
Irf Irf1, Irf2, Irf3, Irf4, Irf5, Irf6, Irf7, Irf8
Iunb Iunb123, Iunb234, Iunb345, Iunb456, Iunb567, Iunb678
P1, P2, P3, P4, P5, P6, P7, P8
P P12, P23, P34, P45, P56, P67, P78
P123, P234, P345, P456, P567, P678
Pfnd1, Pfnd2, Pfnd3, Pfnd4, Pfnd5, Pfnd6, Pfnd7, Pfnd8
Pfnd Pfnd12, Pfnd23, Pfnd34, Pfnd45, Pfnd56, Pfnd67, Pfnd78
Pfnd123, Pfnd234, Pfnd345, Pfnd456, Pfnd567, Pfnd678
S1, S2, S3, S4, S5, S6, S7, S8
S S12, S23, S34, S45, S56, S67, S78
S123, S234, S345, S456, S567, S678
Sfnd1, Sfnd2, Sfnd3, Sfnd4, Sfnd5, Sfnd6, Sfnd7, Sfnd8
Sfnd Sfnd12, Sfnd23, Sfnd34, Sfnd45, Sfnd56, Sfnd67, Sfnd78
Sfnd123, Sfnd234, Sfnd345, Sfnd456, Sfnd567, Sfnd678
Q1, Q2, Q3, Q4, Q5, Q6, Q7, Q8
Q Q12, Q23, Q34, Q45, Q56, Q67, Q78
Q123, Q234, Q345, Q456, Q567, Q678
Qfnd1, Qfnd2, Qfnd3, Qfnd4, Qfnd5, Qfnd6, Qfnd7, Qfnd8
Qfnd Qfnd12, Qfnd23, Qfnd34, Qfnd45, Qfnd56, Qfnd67, Qfnd78
Qfnd123, Qfnd234, Qfnd345, Qfnd456, Qfnd567, Qfnd678
PF1, PF2, PF3, PF4, PF5, PF6, PF7, PF8
λ PF12, PF23, PF34, PF45, PF56, PF67, PF78
PF123, PF234, PF345, PF456, PF567, PF678
PFfnd1, PFfnd2, PFfnd3, PFfnd4, PFfnd5, PFfnd6, PFfnd7, PFfnd8
PFfnd12, PFfnd23, PFfnd34, PFfnd45, PFfnd56, PFfnd67, PFfnd78
λfnd
PFfnd123, PFfnd234, PFfnd345, PFfnd456, PFfnd567, PFfnd678
θU Udeg1, Udeg2, Udeg3, Udeg4, Udeg5, Udeg6, Udeg7, Udeg8
θI Ideg1, Ideg2, Ideg3, Ideg4, Ideg5, Ideg6, Ideg7, Ideg8
DEG1, DEG2, DEG3, DEG4, DEG5, DEG6, DEG7, DEG8
DEG12, DEG23, DEG34, DEG45, DEG56, DEG67, DEG78
φ
DEG123, DEG234, DEG345, DEG456, DEG567, DEG678
fU FU1, FU2, FU3, FU4, FU5, FU6, FU7, FU8
fI FI1, FI2, FI3, FI4, FI5, FI6, FI7, FI8
Ih+ PIH1, PIH2, PIH3, PIH4, PIH5, PIH6, PIH7, PIH8
Ih− MIH1, MIH2, MIH3, MIH4, MIH5, MIH6, MIH7, MIH8
