CLAMP ON POWER LOGGER
short-circuits and electrical accidents
Eliminate the risk of
Septiembre, 31
Tel. 913000191
28022 Madrid
Fax. 913885433
PW3365
Power Measuring Instruments
The world's first instrument to offer
no-metal-contact power measurement
Free from the risk of short-circuit accidents since no
metal comes into contact with energized parts, the
Clamp On Power Logger PW3365-20 can measure
voltage, current, and power right on the cable, letting
you safely test in locations that were dangerous or
even impossible in the past.
www.idm-instrumentos.es
idm@idm-instrumentos.es

Advertisement

loading
Need help?

Need help?

Do you have a question about the PW3365 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hioki PW3365

Summary of Contents for Hioki PW3365

  • Page 1 Free from the risk of short-circuit accidents since no metal comes into contact with energized parts, the Clamp On Power Logger PW3365-20 can measure voltage, current, and power right on the cable, letting you safely test in locations that were dangerous or even impossible in the past.
  • Page 2 Safe, Easy, Voltage Measurement The PW3365-20’s dedicated voltage sensor delivers the world’s first no-metal-contact measurement. Free yourself from the risk of short-circuits by measuring right on the cable sheath without ever needing to touch metal to energized parts Freely clip either...
  • Page 3 ±1.5% rdg. ±0.2% f.s. (combined accuracy with PW3365-20) includes relay box on cord Effect of phase Accuracy combined with the PW3365-20 is within ±1.3% (at 50/60Hz, f.s. input) Maximum rated Soil, residue, or moisture on the insulated wires CATIV 300V / CATIII 600V...
  • Page 4 If you receive a FAIL result, the instrument will also indicate the location of the problem. Setup Flow (example: 3P4W) Quick Set START / Choose the wire type STEP1 Connect the leads to the PW3365-20 STEP2 Connect the voltage sensor STEP3 Connect the clamp sensors STEP4...
  • Page 5 Review Results Display measured values as a graph At the and evaluate results at a glance Worksite Measured values can be displayed as a graph, which is convenient when using the instrument in power management applications. Since you can statistically review not only the measured value at that moment, but also measured values that have been recorded, it’s easy to check values on the spot.
  • Page 6 Download the measurement results to a computer via the power logger's LAN or USB interface or its SD card. Once data has been downloaded, it can be graphed easily with free software. For more detailed analysis, Hioki’s optional SF1001 application software is recommended. Storage media for data...
  • Page 7 Convenient Functions For the More Uses for the PW3365-20 Worksite The Hioki PW3365-20 is not just a power logger. Added-value features and functions let you meet many other electrical testing applications. Leakage Current Measurement Requires optional clamp-on leak sensor Measure power + 1-channel of leakage current...
  • Page 8 Total display range: Within 0 to 130% of the range (“0W” display indicates zero rms voltage and/or current) Effective measurement area: Within 5 to 130% of the range Voltage : ±1.5% rdg. ±0.2% f.s. (combined accuracy with PW3365-20 + PW9020) Measurement accuracy Current : ±0.3% rdg.
  • Page 9 Current input section: Depends on clamp sensor in use. S a v e i n t e r v a l 1/2/5/10/15/30 seconds, 1/2/5/10/15/20/30/60 minutes time Available storage time is displayed on the PW3365-20's setting screen Dielectric strength 7.06 kVrms AC Measurement save : Average only/average, maximum, minimum...
  • Page 10 CT9667-03 Not used for power measurements Not used for power measurements LR06 alkaline battery × 2 or Power supply Notes *Maximum AC measurement range with Maximum AC measurement range with AC ADAPTER 9445-02/9445-03 (optional) PW3365-20 is 5A PW3365-20 is 5A...
  • Page 11 Measurement Range Configurations Combined Accuracy PW3365-20 + PW9020 + clamp sensors Range CLAMP ON SENSOR 9694 / 9695-02 9694 9695-02 ±2.3% rdg. ±0.32% f.s. 50.000A Current Voltage Connection ±2.3% rdg. ±0.4% f.s. 10.000A 500.00mA 1.0000A 5.0000A 10.000A 50.000A ±2.3% rdg. ±0.32% f.s.
  • Page 12 USB cable (1) Spiral tubes (10) Clamp On Power Logger PW3365-20 by itself does not support current and power measurements. Current and power measurements require clamp on sensors, sold separately. Use only HIOKI SD cards guaranteed to work for saving measurement data (options, sold separately).
