SA800U-WF Hardware Design
The following figure shows the thermal dissipation area:
Figure 33: Thermal Dissipation
NOTE
If a conformal coating is necessary for the module, do NOT use any coating material that may chemically
react with the PCB or shielding cover, and prevent the coating material from flowing into the module.
SA800U-WF_Hardware_Design
94 / 106
