Industrial Electronic Devices
POWER SUPPLY:
The devices can be powered at 8...24V AC and 12...35V DC. For more details see the two tables below.
Consumption at 24V DC:
ADFweb.com Srl – IT31010 – Mareno – Treviso
VAC
Vmin
Vmax
8V
24V
Device
HD67813-KNX-232-B2
HD67813-KNX-485-B2
User Manual Modbus Slave / KNX
Document code: MN67813_ENG
VDC
Vmin
Vmax
12V
35V
Consumption [W/VA]
3.5
3.5
Caution: Not reverse the polarity power
HD67813-KNX-232-B2
HD67813-KNX-485-B2
INFO:
www.adfweb.com
Revision 1.003
Pagina 8 di 26
Phone +39.0438.30.91.31
