4. Connector Pinouts on Module
This chapter describes connectors and pinouts, LEDs and switches that are used on the module but are not included in the PICMG standard
specification
Connector and LED Locations
XDP
60-pin
to CPU
BIOS
Defaults
Reset
Switch
CD
AB
FAN
40-pin Debug
4-pin
Connector
Fan
cExpress-BL
Page 31
