SATA Port Configuration
Software Feature Mask Configuration
RAID0
RAID1
RAID10
RAID5
Intel Rapid Recovery Technology
OROM UI and BANNER
HDD Unlock
LED Locate
IRRT Only on ESATA
Smart Response Technology
OROM UI Delay
7.3.4.1. Advanced > SATA > SATA Port Configuration
Feature
SATA Port Configuration
Port X
Hot Plug
Mechanical Presence
External SATA
SATA Device Type
Spin up Device
7.3.5. Advanced > USB
Options
Submenu
Info only
Enabled
Disabled
Enabled
Disabled
Enabled
Disabled
Enabled
Disabled
Enabled
Disabled
Enabled
Disabled
Enabled
Disabled
Enabled
Disabled
Enabled
Disabled
Enabled
Disabled
2 Seconds
4 Seconds
6 Seconds
8 Seconds
Options
Info only
Disabled
Enabled
Disabled
Enabled
Disabled
Enabled
Disabled
Enabled
Hard Disk Drive
Sold State Drive
Disabled
Enabled
Description
Enable / Disable RAID0 feature.
Enable / Disable RAID1 feature.
Enable / Disable RAID10 feature.
Enable / Disable RAID5 feature.
Enable / Disable Intel Rapid Recovery Technology.
If enabled, then the OROM UI is shown. Otherwise, no OROM banner or
information will be displayed if all disks and RAID volumes are Normal.
If enabled, indicates that the HDD password unlock in the OS is enabled.
If enabled, indicates that the LED/SGPIO hardware is attached and ping to
locate feature is enabled on the OS.
If enabled, then only IRRT volumes can span internal and eSATA drives. If
disabled, then any RAID volume can span internal and eSATA drives.
Enable / Disable Smart Response Technology.
If enabled, indicates the delay of the OROM UI Splash Screen in a normal
status.
Description
Enable / Disable SATA Port.
Designates this port as Hot Pluggable.
Controls reporting if this port has an Mechanical Presence Switch.\n\nNote:
Requires hardware support.
External SATA Support.
Identify the SATA port is connected to Solid State Drive or Hard Disk Drive.
On an edge detect from 0 to 1, the PCH starts a COMRESET initialization
sequence to the device.
