ADLINK Technology COM Express cExpress-BL User Manual page 13

Row A
Pin Name
A36 USB6-
A37 USB6+
A38 USB_6_7_OC#
A39 USB4-
A40
USB4+
A41 GND (FIXED)
A42 USB2-
A43 USB2+
A44 USB_2_3_OC#
A45 USB0-
A46 USB0+
A47
VCC_RTC
A48 EXCD0_PERST#
A49 EXCD0_CPPE#
A50 LPC_SERIRQ
A51 GND (FIXED)
A52 PCIE_TX5+
A53 PCIE_TX5-
A54 GPI0
A55 PCIE_TX4+
A56 PCIE_TX4-
A57 GND
A58 PCIE_TX3+
A59 PCIE_TX3-
A60 GND (FIXED)
A61 PCIE_TX2+
A62 PCIE_TX2-
A63 GPI1
A64 PCIE_TX1+
A65 PCIE_TX1-
A66 GND
A67
GPI2
A68
PCIE_TX0+
A69 PCIE_TX0-
A70 GND (FIXED)
LVDS_A0+
A71
(eDP_TX2+)*
LVDS_A0-
A72
(eDP_TX2+)*
LVDS_A1+
A73
(eDP_TX1+ )*
LVDS_A1-
A74
(eDP_TX1- )*
LVDS_A2+
A75
(eDP_TX0+ )*
LVDS_A2-
A76
(eDP_TX0- )*
LVDS_VDD_EN
A77
(eDP_VDD_EN)*
A78 LVDS_A3+
A79 LVDS_A3-
Row B
Pin Name
B36 USB7-
B37 USB7+
B38 USB_4_5_OC#
B39 USB5-
B40
USB5+
B41 GND (FIXED)
B42 USB3-
B43 USB3+
B44 USB_0_1_OC#
B45 USB1-
B46 USB1+
B47
EXCD1_PERST#
B48 EXCD1_CPPE#
B49 SYS_RESET#
B50 CB_RESET#
B51 GND (FIXED)
B52 PCIE_RX5+
B53 PCIE_RX5-
B54 GPO1
B55 PCIE_RX4+
B56 PCIE_RX4-
B57 GPO2
B58 PCIE_RX3+
B59 PCIE_RX3-
B60 GND (FIXED)
B61 PCIE_RX2+
B62 PCIE_RX2-
B63 GPO3
B64 PCIE_RX1+
B65 PCIE_RX1-
B66 WAKE0#
B67
WAKE1#
B68
PCIE_RX0+
B69 PCIE_RX0-
B70 GND (FIXED)
B71 LVDS_B0+
B72 LVDS_B0-
B73 LVDS_B1+
B74 LVDS_B1-
B75 LVDS_B2+
B76 LVDS_B2-
B77 LVDS_B3+
B78 LVDS_B3-
LVDS_BKLT_EN
B79
(eDP_BKLT_EN)*
Row C
Pin Name
C36
DDI3_CTRLCLK_AUX+
C37
DDI3_CTRLDATA_AUX-
C38
DDI3_DDC_AUX_SEL
C39 DDI3_PAIR0+
C40
DDI3_PAIR0-
C41 GND (FIXED)
C42 DDI3_PAIR1+
C43 DDI3_PAIR1-
C44 DDI3_HPD
C45 RSVD
C46 DDI3_PAIR2+
C47
DDI3_PAIR2-
C48 RSVD
C49 DDI3_PAIR3+
C50 DDI3_PAIR3-
C51 GND (FIXED)
C52 PEG_RX0+
C53 PEG_RX0-
C54 TYPE0#
C55 PEG_RX1+
C56 PEG_RX1-
C57 TYPE1#
C58 PEG_RX2+
C59 PEG_RX2-
C60 GND (FIXED)
C61 PEG_RX3+
C62 PEG_RX3-
C63 RSVD
C64 RSVD
C65 PEG_RX4+
C66 PEG_RX4-
C67
RSVD
C68
PEG_RX5+
C69 PEG_RX5-
C70 GND (FIXED)
C71 PEG_RX6+
C72 PEG_RX6-
C73 GND
C74 PEG_RX7+
C75 PEG_RX7-
C76 GND
C77 RSVD
C78 PEG_RX8+
C79 PEG_RX8-
cExpress-BL
Row D
Pin Name
D36 DDI1_PAIR3+
D37 DDI1_PAIR3-
D38 RSVD
D39 DDI2_PAIR0+
D40
DDI2_PAIR0-
D41 GND (FIXED)
D42 DDI2_PAIR1+
D43 DDI2_PAIR1-
D44 DDI2_HPD
D45 RSVD
D46 DDI2_PAIR2+
D47
DDI2_PAIR2-
D48 RSVD
D49 DDI2_PAIR3+
D50 DDI2_PAIR3-
D51 GND (FIXED)
D52 PEG_TX0+
D53 PEG_TX0-
D54 PEG_LANE_RV#
D55 PEG_TX1+
D56 PEG_TX1-
D57 TYPE2#
D58 PEG_TX2+
D59 PEG_TX2-
D60 GND (FIXED)
D61 PEG_TX3+
D62 PEG_TX3-
D63 RSVD
D64 RSVD
D65 PEG_TX4+
D66 PEG_TX4-
D67
GND
D68
PEG_TX5+
D69 PEG_TX5-
D70 GND (FIXED)
D71 PEG_TX6+
D72 PEG_TX6-
D73 GND
D74 PEG_TX7+
D75 PEG_TX7-
D76 GND
D77 RSVD
D78 PEG_TX8+
D79 PEG_TX8-
