2.10. Debug

40-pin flat cable connector to be used with DB-40 debug module
Supports: BIOS POST code LED, BMC access, SPI BIOS flashing, power testpoints, debug LEDs
60-pin XDP header for ICE debug of CPU/chipset

2.11. Power Specifications

Power Modes:
Standard Voltage Input: ATX = 12V±5% / 5Vsb ±5% or AT = 12V±5%
Wide Voltage Input:
Power Management:
Power States:
ECO mode:

2.12. Operating Temperatures

Standard Operating Temperature:
Extreme Rugged™ Operating Temperature (optional): -40°C to +85°C (Standard Voltage Input)

2.13. Environmental

Humidity:
Shock and Vibration:
HALT:

2.14. Specification Compliance

PICMG COM.0: Rev 2.1 Type 6, Compact size 95 x 95 mm

2.15. Operating Systems

Standard Support:
Extended Support (BSP):
AT and ATX mode (AT mode startup controlled by SEMA Board Controller)
ATX = 5~20 V / 5Vsb ±5% or AT = 5 ~20V
ACPI 5.0 compliant, Smart Battery support
supports C1-C6, S0, S3, S4, S5 (Wake-on-USB S3/S4, WoL S3/S4/S5)
supports deep S5 for 5Vsb power saving
5-90% RH operating, non-condensing
5-95% RH storage (and operating with conformal coating).
IEC 60068-2-64 and IEC-60068-2-27
MIL-STD-202F, Method 213B, Table 213-I, Condition A and Method 214A, Table 214-I, Condition D
Thermal Stress, Vibration Stress, Thermal Shock and Combined Test
Windows 7/8.1u 32/64-bit, Linux 32/64-bit
Windows Embedded Standard 7 (WES7), Windows Embedded 8 Standard (WE8S), Linux, VxWorks
0°C to +60°C (Wide Voltage Input)
