4.2.

Status LEDs

To facilitate easier maintenance, status LED's are mounted on the board.
LED Descriptions
Name Color
LED1 Blue
LED2 Green
LED3 Red
Page 34
Connection Function
BMC output Power Sequence Status Code (BMC)
Power Changes, RESET
(see 5.1.4 Exception Codes below)
Power Source 3Vcc S0
S3/S4/S5
ECO mode
BMC output Module power up
Watchdog counting
and same signal as WDT
Watchdog timed out
(B27) on BtB connector
Watchdog RESET
Rebooted after WD RESET WD LED = LED ON
Rebooted after PWRBTN WD LED = LED ON
Rebooted after RESET BTN WD LED = LED OFF
Note: only a RESET not initiated by the BMC can clear the WD LED (user action)
LED ON
LED OFF
LED OFF
WD LED = LED OFF
WD LED = LED OFF
WD LED = LED ON
WD LED = LED ON
