1. Front brake hose (hydraulic unit to front brake
caliper)
2. Front wheel sensor lead
3. Wire harness
4. Starter motor lead
5. Throttle cable (decelerator cable)
6. Throttle cable (accelerator cable)
7. Sidestand switch lead
8. Fuel tank cap lid lock cable
9. Main switch coupler
10. Handlebar switch coupler (right handlebar switch)
11. Handlebar switch lead (left handlebar switch)
12. Handlebar switch lead (right handlebar switch)
13. Main switch lead
14. Seat lock cable
15. ECU (Engine Control Unit)
16. Radiator fan motor relay
17. Rollover valve
18. Starting circuit cut-off relay
19. Rectifier/regulator
20. Main switch
21. Rear brake hose (hydraulic unit to rear brake
caliper)
22. Front storage compartment lock cable
23. Rectifier/regulator coupler
24. Horn
A. Position the tapes on the right handlebar switch
lead and left handlebar switch lead to the rear of
the guide on the frame.
B. Position the fan motor relay and starting circuit cut-
off relay in any order.
C. Insert the projection on the wire harness holder
(tape) into the hole in the frame.
D. Point the end of the plastic band outward.
E. Install the coupler cover completely until it contacts
the rectifier/regulator.
2-18
CABLE ROUTING
