Removing the engine
45 N m (4.5 kgf m, 33 lb
• •
3
2
Order
1 Rear shock absorber assembly
2 Engine mounting nut/bolt (front side)
3 Engine mounting nut/bolt (rear side)
4 Engine
5 Starter motor lead
6 Engine bracket nut/bolt
7 Engine bracket
ft)
•
3
2
3
7
2
Job/Parts to remove
23 N m (2.3 kgf m, 17 lb
• • •
45 N m (4.5 kgf m, 33 lb
• •
60 N m (6.0 kgf m, 44 lb
• •
3.5 N m (0.35 kgf
•
6
5
4
'
Q ty
2
2/2
2/2
1
1 Disconnect.
1/1
1
5-10
ENGINE REMOVAL
