Disconnecting the leads
Order
Thermostat assembly
Fuel injector
Air filter case joint
Intake manifold
1 Crankshaft position sensor coupler
2 Stator coil coupler
3 Coolant temperature sensor coupler
4 O sensor coupler
2
5 Spark plug cap
6 Engine ground lead
7 Rear wheel sensor coupler
3
5
Job/Parts to remove
6
1
4
'
Q ty
Refer to "THERMOSTAT" on page 6-6.
Refer to "FUEL INJECTOR" on page 7-8.
Refer to "AIR FILTER CASE" on page 7-11.
Refer to "THROTTLE BODY" on page 7-13.
1 Disconnect.
1 Disconnect.
1 Disconnect.
1 Disconnect.
1 Disconnect.
1 Disconnect.
1 Disconnect.
5-9
ENGINE REMOVAL
7 N m (0.7 kgf m, 5.2 lb ft)
• • •
7
2
Remarks
