Disassembling the front fork legs
9 New
LT LT
LT
8
30 N m (3.0 kgf m, 22 lb
• •
Order
1 Front fork cap bolt
2 O-ring
3 Spacer
4 Spring seat
5 Fork spring
6 Dust seal
7 Oil seal clip
8 Front fork damper rod bolt
9 Copper washer
10 Damper rod
LS
7
New
New
New
ft)
•
Job/Parts to remove
6 New
New
'
Q ty
The following procedure applies to both of
the front fork legs.
1
1
1
1
1
1
1
1
1
1
4-80
FRONT FORK
