Defining a fixed IP address with an SD card:
. Create a text file on your PC, named "IP.TXT".
. The first line in this file must hold the IP address.
. The second line is optional and can hold the IP mask.
. Copy "IP.TXT" to the root directory of an SD card.
. Insert the SD card into the V-Tap unit.
. The IP address has now changed and can be accessed.
. The file "IP.TXT" is deleted from the card by the V-Tap.
. Note: The IP address 0.0.0.0 enables DHCP on the V-Tap.

3.2 Web interface

Entering the IP address in your browser will show the following screen:
Now enter "admin" for the User name and "admin" for the Password,
then press the Login button and the Settings menu appears (
on the next page
(The settings on the next page are not the default settings, but just an example.)
V-Tap ISDN PRI Manual EN v1.3 Okt 2018
).
see picture
