Quick Guide for the V-Tap Analog
The V-Tap Analog is a device that can record the audio from an analog
telephone line or any telephone that works with a handset. The recorded calls
are stored onto an SD card and can optionally be sent to an external server,
which can be a
Call Recorder Apresa
NOTE1: The USB power supply needs to deliver 500 mA current, else the system does not start.
NOTE2: When no analog line is connected or when no SD card is inserted, the Red LED starts
flashing on first power on, to indicate an error situation.
NOTE3: The SD card must be formatted with the FAT32 file system. Cards above 32 GB (up to 2 TB)
are not tested and must be formatted as FAT32 first, before inserting them into the V-Tap.
• V-Tap Analog unit
• USB adapter
• USB cable
• Telephone cable
• SD card
• 1 year Support & Update license
• This Quick Guide
• Manual:
https://www.vidicode.com/download/v-tap-analog-manual-en/
• V-Archive PC software:
v1.17
or the
V-Archive software
BOX CONTENT & DOWNLOADS
https://www.vidicode.com/download/v-archive/
© 2017-2021 Vidicode
running on a PC.
1/4
