C LVDS P
OMPATIBLE
The following flat panel displays are reported to work properly with the integrated graphics
video controller chip used on the EBX-11.
Manufacturer
eVision Displays
au Optronix
eVision Displays
au Optronix
eVision Displays
Sharp
C R
ONSOLE EDIRECTION
The EBX-11 can be operated without using the on-board video output by redirecting the console
to COM1. CMOS Setup and some operating systems such as DOS can use this console for user
interaction.
In the Features Configuration screen, there is an option to control console redirection. This
option can be set to Auto or Redirect. When set to Auto, the console will not be redirected to
COM1 unless a signal is detected from the terminal by pressing and holding down CRTL-C.
When set to Redirect, the console will be directed to COM1.
Notes on console redirection:

When console redirection is enabled, you can access CMOS Setup by typing Ctrl-C.

The decision to redirect the console is made early in BIOS execution and cannot be
changed later.

The redirected console uses 115200 baud, 8 data bits, 1 stop bit, no parity, and no flow
control.

The default console redirection setting is Auto. The default can be reloaded without
entering BIOS setup by discharging CMOS contents.
Null Modem:
The following diagram illustrates a typical DB9 to DB9 RS-232 null modem adapter. Pins 7 and
8 are shorted together on each connector. Unlisted pins have no connection.
System 1 <-->
Name Pin
------------------------
TX 3 <-->
RX 2 <-->
RTS 7 <-->
CTS 8
DSR 6 <-->
DCD 1 <-->
DTR 4 <-->
EBX-11 Reference manual
D
ANEL ISPLAYS
Table 19: Compatible Flat Panel Displays
Panel
Model Number Size
8.4"
xxx084S01 series
8.4"
B084SN01
10.4"
xxx104S01 series
10.4"
B104SN01
14.1"
xxx141X01 series
12.1"
LQ121S1LG411
System 2
Pin Name
2 RX
3 TX
1 DCD
4 DTR
7 RTS
8 CTS
6 DSR
Resolution Interface
800 x 600 18-bit LVDS
800 x 600 18-bit LVDS
800 x 600 18-bit LVDS
800 x 600 18-bit LVDS
1024 x 768 18-bit LVDS
800 x 600 18-bit LVDS
Interfaces and Connectors
Panel
Technology
TFT
TFT
TFT
TFT
TFT
TFT
