EBX-11 C
ONNECTOR
The following table notes the function of each connector, as well as mating connectors and
cables, and the page where a detailed pinout or further information is available.
Connector Function
J1 Ethernet 0
J2 Ethernet 1
J3 Main Power Input
(EBX Compliant)
J4 COM 1-4, PLED,
PS/2 Keyboard
and Mouse, Reset
Button, Speaker
J5 Analog I/O, PWM
I/O, Digital I/O
J6 SVGA Video
Output
J7 PC-104-Plus
J9 LVDS
J10 Audio, Digital I/O,
USB 0-1
J11 CompactFlash
J12 IDE Hard Drive
J14, J15 PC/104
J16 PLD Reprogram-
ming Port (Factory
use Only)
J17 SPX I/O
J18 LPT
3
J20 USB 2
J21 USB 3
1. The PCB origin is the mounting hole to the lower left, as oriented in Figure 9.
2. CBR-4405 44-pin to 40-pin adapter required to connect to 3.5-inch IDE drives with 40-pin connectors.
3. On Rev. 4.01 and earlier boards, one connector (J13) provided the interface to both USB2 and USB3. The connector was a
2mm 10-pin header. See Table 15 for a pinout of this connector.
EBX-11 Reference Manual
F I
UNCTIONS AND NTERFACE
Table 1: Connector Functions and Interface Cables
Transition
Mating Connector
–
RJ45 Crimp-on Plug
–
RJ45 Crimp-on Plug
Molex 39-01-2100 CBR-2022
Molex 39-00-0059 (10 ea.)
FCI 89361-350LF CBR-5009A
FCI 89361-340LF CBR-4004A
FCI 89361-712LF or CBR-1201
FCI 89947-712LF
–
AMP 1375799-1
20-pin, PanelMate 1.25mm CBR-2010
or
CBR-2011
FCI 89361-340LF CBR-4004A
–
Type I or Type II
Compact Flash
FCI 89947-144LF CBR-4406
CBR-4405
–
AMP 1375795-2
– –
FCI 89361714LF CBR-1401 or
CBR-1402
FCI 89361720LF CBR-2003
–
Standard USB Series A
–
Standard USB Series A
C
ABLES
Cable Description
Cable
–
–
6" ATX to EPIC power
cable
18" 2mm 50-pin to 50-
pin IDC to breakout
board CBR-5009B
12" 2mm 40-pin to 40-
pin IDC to screw
terminal board
CBR-4004B
1' 12-pin 2mm IDC to
15-pin HD D-Sub VGA
–
18-bit TFT FPD using
20-pin Hirose
18-bit TFT FPD using
20-pin JAE
12" 2mm 40-pin to 40-
pin IDC to screw
terminal board CBR-
4004B
–
18" 2mm IDE cable
2
2mm to 0.1" adapter
–
–
2mm 14-pin IDC, 2 or 4
SPX device cable
12" 2mm 20-pin IDC
LPT
–
–
Physical Details
1
Pin 1 Location Page
x coord. y coord.
0.425 4.200 42
0.425 5.500 42
0.625 6.600 22
0.380 7.200 26
0.380 7.520 27
1.700 0.060 39
–
2.106 3.096
2.400 0.190 40
2.325 7.520 29
3.263 4.501 37
2.640 7.200 30
–
5.050 2.700
–
4.900 6.025
4.280 6.950 55
4.270 7.520 33
5.320 0.642 35
5.320 1.337 35
17
