Accelnet & Stepnet Plus Panels User Guide
2.2 A P
CCELNET
Network
EtherCAT
CANopen
MACRO
Ic = Continuous Output Current, Adc (peak of sine)
Ip = Peak Output Current, Adc (peak of sine)
Vdc = HV power supply voltage (DC, line-isolated)
The models listed above are available with the following options added to the part number:
-R: Resolver feedback (Example BEL-090-14-R). Resolver feedback not available on BML models.
-H: Factory-installed heatsink (Example: BEL-090-14-H)
-R-H: Resolver option with factory-installed heatsink (Example: BEL-090-14-R-H)
2.3 S P
TEPNET LUS
Network
EtherCAT
CANopen
Ic = Continuous Current, Adc (peak of sine)
Ip = Peak Current, Adc (peak of sine)
Vdc = HV power supply voltage (DC, line-isolated)
The models listed above are available with the following option added to the part number:
-H: Factory-installed heatsink (Example: TEL-090-10-H)
P M
LUS ANEL ODELS
Axes Models
BEL-090-06
1-Axis BEL-090-14
BEL-090-30
BE2-090-06
2-Axis BE2-090-14
BE2-090-20
BPL-090-06
1-Axis BPL-090-14
BPL-090-30
BP2-090-06
2-Axis BP2-090-14
BP2-090-20
BML-090-06
1-Axis BML-090-14
BML-090-30
P M
ANEL ODELS
Axes Models
TEL-090-07
1-Axis
TEL-090-10
TE2-090-07
2-Axis
TE2-090-10
TP2-090-07
2-Axis
TP2-090-10
Ic Ip Vdc
3 6
7 14
15 30
3 6
7 14
10 20
3 6
7 14 14~90
15 30
3 6
7 14
10 20
3 6
7 14
15 30
Ic Ip
5 7
10 10
5 7
14~90
10 10
5 7
10 10
16-01339 Rev 07
Vdc
