5.3 Accelnet Plus Panel Models
Network
EtherCAT
CANopen
Ic = Continuous Output Current, Adc (peak of sine)
Ip = Peak Output Current, Adc (peak of sine)
Vdc = HV power supply voltage (DC, line-isolated)
The models listed above are available with the following options added to the part number:
-R: Resolver feedback (Example BEL-090-14-R)
-H: Factory-installed heatsink (Example: BEL-090-14-H)
-R-H: Resolver option with factory-installed heatsink (Example: BEL-090-14-R-H)
5.4 Stepnet Plus Panel Models
Network
EtherCAT
CANopen
Ic = Continuous Current, Adc (peak of sine)
Ip = Peak Current, Adc (peak of sine)
Vdc = HV power supply voltage (DC, line-isolated)
The models listed above are available with the following option added to the part number:
-H: Factory-installed heatsink (Example: TEL-090-14-H)
Page 12 of 34
Axes
Models
BEL-090-06
1-Axis
BEL-090-14
BEL-090-30
BE2-090-06
2-Axis
BE2-090-14
BE2-090-20
BPL-090-06
1-Axis
BPL-090-14
BPL-090-30
BP2-090-06
2-Axis
BP2-090-14
BP2-090-20
Axes
Models
TEL-090-06
1-Axis
TEL-090-14
TE2-090-07
2-Axis
TE2-090-10
TP2-090-07
2-Axis
TP2-090-10
Ic
Ip
Vdc
3
6
7
14
15
30
3
6
7
14
10
20
14~90
3
6
7
14
15
30
3
6
7
14
10
20
Ic
Ip
Vdc
3
6
7
14
5
7
14~90
5
10
5
7
5
10
16-01338 Rev 00
