Accelnet & Stepnet Plus Panels User Guide
5.5 P C
OWER ONNECTOR
TEL, TE2, TP2 - DC P
P R
OWER ECEPTACLE
Description
Manufacturer PN
P C P
OWER ABLE
Description
Manufacturer PN
Wire size
Recommended Wire
Wire Insertion/Extraction Tool
Connectors and tool are included in Connector Kits TEL-CK, TE2-CK, and TP2-CK.
P D
IN ESCRIPTIONS
Pin Signal
1 0V
2 +HV
3 AuxHV
E L F
MI INE ILTER
Manufacturer
Part Number
L
OCATIONS
OWER
Euro-style 5.08 mm, 3-position, male receptacle
Wago: 231-563/108-000
LUG
Euro-style 5.08 mm plug
Wago: 231-303/107-000
22~14 AWG
22~14 AWG, 600 V
Shielded cable required for CE compliance
Wago: 231-159
Function
DC power input (-), also internal: Signal Ground
DC power input (+)
Aux DC power input for logic power
TE Connectivity (Corcom)
20ERK1 used for the TE2, TP2
10ERK1 used for the TEL
– S
M
TEPNET ODELS
16-01339 Rev 07
