Quad A/B/X Digital Encoders
Q A/B/X E
UAD
BEL, BPL, BML
Input
Type Signal
Quad A Enc A
Quad /A Enc /A
Quad B Enc B
Quad /B Enc /B
Quad X Enc X
Quad /X Enc /X
Signal Ground
BE2, BP2, TE2, TP2
Input
Type
Quad A
Quad /A Enc /A
Quad B
Quad /B Enc /B
Quad X
Quad /X Enc /X
Signal Ground
NCODER
TEL
AND
J1
J1 Pins
36
21
35
20
34
19
6,16,22,31,37,44
J1 J1 Pins J1 Pins
Signal Axis-A Axis-B
Enc A 36 42
21 27
Enc B 35 41
20 26
Enc X 34 40
19 25
6,16,22,31,37,44
