Accelnet & Stepnet Plus Panels User Guide
A I
NALOG NPUTS
The analog inputs have a ±10 Vdc range at 12-bit resolution
As reference inputs they can take position/velocity/torque commands from a controller.
If not used as command inputs, they can be used as general-purpose analog inputs.
A I W
NALOG NPUT
Signal
Analog Ref(+)
Analog Ref(-)
Signal Ground
Frame Ground
D
IRING IAGRAM
BEL, BPL,
BML,TEL
J1 Pins
3
2
6,16,22,31,37,44
1
BE2, BP2, TE2, TP2
J1 Axis-A Pins J1 Axis-B Pins
3
2
6,16,22,31,37,44
1
16-01339 Rev 07
5
4
