Accelnet & Stepnet Plus Panels User Guide
BEL, BPL, BE2, BP2 - M
M R
OTOR ECEPTACLE
Description
Manufacturer PN
M C P
OTOR ABLE
Description
Manufacturer PN
Wire Size
Recommended Wire
Wire Insertion/Extraction Tool
Connectors and tool are included in Connector Kits BEL-CK, BPL-CK, BE2-CK, and BP2-CK.
P D
IN ESCRIPTIONS
Pin Signal
1 Ground
2 W
3 V
4 U
C
OTOR ONNECTORS
Euro-style 5.08 mm, 4-position, male receptacle
Wago: 231-564/108-000
LUG
Euro-style, 4 position, 5.08 mm pluggable female terminal
block
Wago: 231-304/107-000
22 - 14 AWG
22~14 AWG, 600 V
Shielded cable required for CE compliance
Wago: 231-131
Function
Motor frame ground and cable shield
Phase W output
Phase V output (brush motor DC(-) connection)
Phase U output (brush motor DC(+) connection)
16-01339 Rev 07
