Accelnet & Stepnet Plus Panels User Guide
4
S
PECIFICATIONS
4.1
DC I
P
NPUT
+HV is required for operation of the drives. AuxHV is optional and powers the communications, feedback, and
I/O functions but not the PWM outputs. AuxHV is recommended for drives operating on a control network
because it enables the network master to maintain communication with the drives when the +HV has been
removed, most commonly for safety or EMO (Emergency Off) conditions.
S
-A
S
INGLE
XIS
ERVO
Model
DC +HV Voltage***
Peak +HV Current
Peak Current Time
Continuous +HV Current
AuxHV Supply Voltage***
AuxHV Supply Current
*The actual +HV current is dependent on the input voltage and motor load and operating conditions.
The Maximum +HV currents shown above occur when the drive is operating from the maximum input
voltage and is producing the rated continuous output current at the maximum output voltage.
** AuxHV supply current depends on the number of encoders connected to the drive. The maximum
current draw given assumes that the encoder +5V output is loaded to 500mA.
*** Supply Short Circuit Current Rating (SCCR) must be 5k Arms maximum
D
-A
S
UAL
XIS
ERVO
Model
DC +HV Voltage***
Peak +HV Current
Peak Current Time
Continuous +HV Current
AuxHV Supply Voltage***
AuxHV Supply Current
*The actual +HV current is dependent on the input voltage and motor load and operating conditions.
The Maximum +HV currents shown above occur when the drive is operating from the maximum input
voltage and is producing the rated continuous output current at the maximum output voltage.
** AuxHV supply current depends on the number of encoders connected to the drive. The maximum
current draw given assumes that the two encoder +5V outputs are each loaded to 500mA.
*** Supply Short Circuit Current Rating (SCCR) must be 5k Arms maximum
OWER
M
: BEL, BPL, BML
ODELS
BEL-090-06
BPL-090-06
BML-090-06
+14 to +90 (
6
3
+14 to +90 (
500 mA maximum
M
: BE2, BP2
ODELS
BE2-090-06
BP2-090-06
+14 to +90 (
12
6
+14 to +90 (
500 mA maximum
BEL-090-14
BPL-090-14
BML-090-14
transformer-isolated from AC mains
14
1
7
transformer-isolated from AC mains
BE2-090-14
BP2-090-14
transformer-isolated from AC mains
28
1
14
transformer-isolated from AC mains
16-01339 Rev 07
BEL-090-30
BPL-090-30
Unit
BML-090-30
)
Vdc
30
Adc
Sec
15
Adc
)
Vdc
Adc**
BE2-090-20
Unit
BP2-090-20
)
Vdc
40
Adc
Sec
20
Adc
)
Vdc
Adc**
