Specifications

Specifications

■
General specifications
Item
Ambient temperature
Ambient humidity
Ambient temperature for
storage
Vibration resistance
Impact resistance
Withstand voltage
Insulation resistance
Operating atmosphere
Pollution degree
Weight
Electrical specifications
Current consumption
in power supply
voltage range
Solenoid valve
connecting
specification
o
-10 to +50 C
35 to 85%RH (No condensation)
o
-20 to +60 C
10 to 57 Hz 0.3 mm (Constant amplitude)
57 to 150 Hz 50 m/s
Peak value 150 m/s
directions.
500 VAC applied for 1 minute
500 VDC, 10 MΩ or more
No corrosive gas
Pollution degree 2
200g or less
Item
Current consumption of
controller power supply
Solenoid valve power
supply
Out put type
(Valve common polarity)
Number of outputs
Connected load
Output setting at the time
of communication error
Insulation type
Residual voltage
Specifications
2
(Constant acceleration)
2
applied for 11 ms three times each in X, Y and Z
Specifications
11 to 25 VDC
0.1 A max.
22.8 to 26.4 VDC
2.0 A or less, according to the solenoid valve station
specification
PNP(-COM.)
EX260-SDN1: 32outputs
EX260-SDN3: 16outputs
Solenoid valve with light and surge voltage suppressor
of 24 VDC and 1.5 W or less (manufactured by SMC)
HOLD/CLEAR
Photo coupler insulation type
0.4 VDC or less
‑34‑
NPN (+COM.)
EX260-SDN2: 32 outputs
EX260-SDN4: 16 outputs
