SMC Networks DeviceNet EX260 Series Operation Manual page 16

Switch setting
Set the DeviceNet
reaction of outputs to the communication error, of the SI unit with 10-element switch.
Note
1.To set with switch, use a small blade screwdriver to flip the switches
2.Be sure to switch off the power when set with switch.
3.Be sure to set with the switch before use.
Address setting (switch No. 5 to 10)
Set the DeviceNet
Note: Factory default setting is 63.
Switch No.
MAC ID
Communication speed setting (switches No. 3 to 4)
Set the DeviceNet
Note: Factory default setting is 125bps.
Switch No.
Communication
speed
TM
node address (MAC ID), DeviceNet communication speed and fail safe mode, i.e.
TM
node address (MAC ID) in binary coded. Address range is 0 to 63.
No.5
32
0 0
1 0
2 0
: :
62 1
63 1
TM
communication speed in binary coded.
No.3
125 kbps 0
250 kbps 0
500 kbps 1
- 1
No.6 No.7 No.8
16 8
0 0
0 0
0 0
: :
1 1
1 1
0: OFF 1: ON
No.4
0
1
0
1
‑15‑
0: OFF 1: ON
No.9 No.10
4 2 1
0 0 0
0 0 1
0 1 0
: : :
1 1 0
1 1 1
EX##‑OMN0013
