3.2Operation procedure
3-8
"Rear display"
9 Press the f key "Tool sph.".
>> The following window will appear.
10 Enter the desired "Tool sphere No."
>> The displayed No. on the f key will be changed.
11 Press the f key "Terminate".
>> The Graphic Display will be closed to return to the "Range setting" screen.
12 After the completion of settings, press the <Complete>.
Side
X
Fig. 3.2.1 Top, Side, and Rear Switching
Top
Rear
Z
Y
