ATI Corporation Level Best Grader Blade Operator's & Parts Manual page 65

Item Part No.
000-201-289
1 316-001-710
2 000-150-409
3 001-001-072
4 000-155-034
5 000-150-131
6 000-150-405
7 316-001-730
8 000-155-020
9 000-150-053
10 000-158-050
11 000-200-522
AR - As Required NSS - Not Serviced Separately
PARTS ILLUSTRATIONS
Figure 2-17. Topcon 3DMC W/Display in Cab
Qty
1 Kit, Topcon 3DMC W/ Screen on Cab, Includes Items 1 thru 11
1 Plate
4 Bolt, Flange, Gr. 10.9, M8-1.25 x 16mm
1 Stand Off
2 Washer, Lock, 3/8"
2 Bolt, Hex Head, 3/8"-16UNC x 1-1/2" Long
1 Bolt, Shoulder, 3/8" Dia. x 2" Shoulder x 5/16"-18UNC
1 Bracket, Slope
6 Washer, Flat, 1/4"
3 Bolt, Hex Head, 1/4"-20UNC x 1-3/4" Long
3 Nut, Hex, Nylon Lock, 1/4"-20UNC
1 Harness, Breakout A, Topcon 3D-MC, 40' Long
ASN - After Serial No. BSN - Before Serial No.
Description
2.37
LP - Local Purchase
