ATI Corporation Level Best Grader Blade Operator's & Parts Manual page 35

Figure 2-2.
Item Part No.
1 316-001-460
2 000-155-104
3 000-150-389
4 000-158-213
5 000-161-202
6 316-001-440
7 316-001-443
8 316-001-444
9 316-001-446
10 000-150-401
11 000-155-115
12 000-158-221
13 316-001-439
14 000-150-404
15 316-001-100
16 000-190-202
17 000-150-258
18 000-158-142
19 316-001-120
20 000-150-396
21 000-158-111
AR - As Required NSS - Not Serviced Separately
PARTS ILLUSTRATIONS
Carriage, Moldboard, Blade and Related Parts
Qty
1 Carriage, Grader Blade, GB-108
2 Washer, Flat, 1-1/2", SAE Std,
1 Bolt, Hex Head, Gr. 8, 1-1/2"-12UNF x 3" Long
1 Nut, Castle, Jam, 1-1/2"-12 UNF
1 Pin, Cotter, 1/4" Dia. x 3" Long
2 Clasp, Carriage, Bolt On
4 Pad, Wear, Clasp, Carriage, Bolt-On
AR Shim, Clasp, Carriage, Bolt-On, 16 Ga.
AR Shim, Clasp, Carriage, Bolt-On, 20 Ga.
6 Bolt, Flange, 3/4"-10UNC x 3-3/4" Long
6 Washer, Flat, Gr. 8. 3/4"
8 Nut, Hex, 3/4"-10UNC,
4 Pad, Wear, Clasp, Carriage, Bolt-On
16 Screw, Socket Head, 5/16"-18UNC x 5/8" Long,
1 Moldboard, Grader Blade, GB-108
1 Edge, Cut, Bolt-On, Curved, DBC, 3/4" x 6" x 108" Long
18 Bolt, Plow, 5/8"-11UNC x 1-3/4" Long
18 Nut, Serrated Flange, 5/8"-11UNC, (128 ft-lbs)
1 Shield, Dirt, Moldboard
4 Bolt, Serrated Flange, 1/2"-13UNC x 1" Long
4 Nut, Serrated Flange, 1/2"-13UNC
ASN - After Serial No. BSN - Before Serial No.
Description
(282 ft-lbs red Loctite)
2.7
(17 ft-lbs blue Loctite)
LP - Local Purchase
